    0.2mm Components 10 Nozzles 35000 CPH Pcb Mounting Machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-E6
    Certification : SIRA.CCC.CE
    Price : 25000-33000 USD
    Payment Terms : T/T, L/C
    Supply Ability : 50 Units per month
    Delivery Time : 30 days
    • Product Details
    • Company Profile

    0.2mm Components 10 Nozzles 35000 CPH Pcb Mounting Machine


    Features Of E6

    Accurately place, manager, and track components with Smart Feeders

    Apply to different kinds of SMD components: LED chip, capacitors, resistors, IC,RGB, shaped components,etc.


    Our Advantage:

    1. There is an adjustable track at the PCB entrance, which can clamp the board from 100*100--350*1200mm well

    2. Fully automatic operation, saving manpower

    3. The smallest mounting component: 0402


    TECHNICAL PARAMETER

    E6T Technical Parameter
    1Length*Width*Height1650mm*1200mm *1570mm
    2Total Weight1200kg
    3PCB Length WidthMax:500*350mm Min:100*100mm
    4PCB Thickness0.5-5mm
    5PCB ClampingElectric clamping
    6Mounting ModeGroup picking and separate placingseparate picking and separate placing
    7SoftwareWindows 7
    8DisplayTouch screen
    9Input DeviceKeyboard,Mouse
    10No. of Camera2 sets of imported camera
    11Position CameraVision for the flight identification + MARK correction
    12Mounting repeat Precision±0.02mm chip
    13Mounting Height<40mm(component max height 20mm)
    14Mounting Speed35000 CPH(optimum)
    15ComponentsLED chip,capacitors,resistors,IC,RGB,shaped components etc.
    16Components Speed0.2mm
    17X,Y,Z Axies DrivingMagnetic linear motor+servo motor
    18feeder stations26PCS
    19No. of nozzles10 nozzles

    Finished products

    It's suitable for power driver, electric boards,LED screen, bulb, down light, panel, strip, lamp, street light, ceiling light and etc
