    CE IQF Ice Cream Industrial Blast Food Freezing Machine

    Ask Lasest Price
    Brand Name : Fude
    Model Number : FD-F-100-1000
    Certification : CE,ISO,UL
    Price : 1000usd-50000usd
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000
    Delivery Time : 7
    • Product Details
    • Company Profile

    CE IQF Ice Cream Industrial Blast Food Freezing Machine

    Dumplings quick iqf tunnel freezer for meatball freeze cold storage design room fast freezing quick cooler

    CE approved industrial blast freezers / iqf freezing machine / tunnel / freeze ice cream machine


    Model No.
    Converyer Size
    (L*W, Meter)
    Inner Dimension
    (L*W*H, Meter)
    Overall Dimension
    (L*W*H, Meter)
    Freeze Capability
    (KGS/Hour)
    JSSD-7-1.3SJ
    7x1.3 (m)
    5.76x1.5x0.4 (m)
    7.22x2.35x1.9 (m)
    800
    JSSD-7-1.5SJ
    7x1.5 (m)
    5.76x1.7x0.4 (m)
    7.22x2.55x1.9 (m)
    1000
    JSSD-9-1.3SJ
    9x1.3 (m)
    7.68x1.5x0.4 (m)
    9.14x2.35x1.9 (m)
    1000
    JSSD-9-1.5SJ
    9x1.5 (m)
    7.68x1.7x0.4 (m)
    9.14x2.55x1.9 (m)
    1300
    JSSD-11-1.3SJ
    11x1.3 (m)
    9.6x1.5x0.4 (m)
    11.06x2.35x1.9 (m)
    1200
    JSSD-11-1.5SJ
    11x1.5 (m)
    9.6x1.7x0.4 (m)
    11.06x2.55x1.9 (m)
    1500
    Note: The freeze capability is average value based on normal products. Actual productivity varies according to the kinds of processing products. Generally thicker or larger products require longer processing time, thus the productivity is smaller.
    Product Name
    Liquid Nitrogen IQF Freezing Tunnels Blast Freezer for Durian
    Working Temperature
    0℃ to -196℃
    Tunnel Temperature
    - 60℃ to -150℃
    Freezing Time
    5 to 120min, stepless adjustable
    Conveyor Operation Time
    10 to 40 minutes, adjustable
    Material Input Height
    50mm to 150mm, adjustable
    Tunnel Inside Effective Height
    400mm
    Diameter of Exhaust Outlet
    300mm

    Features and Performance:

    1. Mesh belt drive: the speed of mesh belt is adjusted stepless by imported inverter, and the freezing
    time is adjustable from 6-60 minutes, which can adapt to the processing of various frozen products.
    2. Ice scraping device for feeding belt to reduce damage to steel belt caused by ice and foreign matter.
    3. Compressor refrigeration, no freon, green protection, odor, antibacterial, energy saving, low operating costs.
    4. Unique Tong efficiency ventilation device, the reasonable air distribution, uniform air distribution, make
    the material fully exposed to the strong cold wind, high freezing efficiency.
    5. Food transport network, transport speed can be flexible according to different products, suitable for a variety
    of frozen food processing.
    6. According to the production requirements can choose single, double net belt combination.
    7. The e belt shall be tightened and adjusted to ensure the smooth and long running of the food conveyor belt.
    8. The storage body is made of rigid polyurethane foam with good insulation performance. The inner and outer
    cover and the inner and outer support of the storage body are made of stainless steel, which is easy to clean and
    meets the requirements of HACCP for food hygiene.
    9. The control system has two automatic and manual cooling modes, which can be selected according to different
    production needs.
    10. With continuous production line, safe and durable, easy to operate, long service life.
    11. Adopt water to flush frost way, safeguard clean sanitation.
    12. The equipment can be customized according to the needs of users.


    Packaging & Shipping
    WHAT ARE THE BENEFITS?
    Liquid Nitrogen Quick Freezing is a method widely used in frozen food industry for things like meat, poultry, prepared foods, fruits, vegetables, beverages or aquatic products, etc. Many commercial kitchens also use liquid nitrogen chilling and freezing technology to store foodstuffs.
    One of the most important benefits a liquid nitrogen quick freezer brings is locking in freshness of produce. Our solutions allow companies to keep food fresh for months at a time before it is no longer suitable for consumption. This is because it slows down the natural decaying process and inhibits bacterial activities that happens in all meats, fish,
    poultry, fruits and vegetables.
    Liquid nitrogen blast freezing technique can be used to preserve essential nutrients found in food, making your produce fresher and healthier.
    Wide Suitability
    0℃ to -196℃ working temperature, freely regulated, 1℃ to 2℃ control precison, fit different kinds of food.
    Improved Productivity
    Freezing speed is 3 times faster than conventional freezers. Product center temperature reaches -18℃ quickly.
    Save Labor Costs
    Optimized mechanical structure makes it easier to be operated, easy to clean and maintain, save labor and time costs.
    Maintain Original Texture and flavor
    0.25% ~ 0.5% low drip loss, instant freezing, preserve original appearance, color, flavor and nutrition of the processed products.
    Safe and Environment-Friendly
    Nitrogen is toxic-free, poisonless and harmless to food, human and the environment. No pollution gas exhausts.
    Low Noise Emission
    No condensor or compressor, small energy consumption, high reliability and performance, low operation noises.
    Widely Used in Food Industries
    As a proven technology, liquid nitrogen freezers are widely applied to aquatic products, bakery products, meat, poultry, fruits, vetegables, etc.
    Improved Food Safety
    Overall body of the equipment is made of SUS304 stainless steel. Nitrogen is non-toxic, poisonless and harmless.
    Utilizes Minimum Amount of Floor Space
    The sizes of liquid nitrogen cryogenic freezers are much smaller comparing with conventional freezers, utilizes a minimum amount of floor space, easy to install and set up.
    Extended Shelf Life and Profitability
    Liquid nitrogen flash freezers perfectly maintain the original texture, color and flavor of food, no damages to cell structures. Processed food have longer shelf-life and better quality.

    Remarks

    ◊Cooling capacity is related to the shape,size,water content and physical properties of the foods.

    To be work in room with temperature under 18℃ is recommended.
    Configure cooling system individually for the IQF.

    High and low pressure compressors work together is recommended.
    ◊Nominal capacity & cold consumption is based on boiled dumplings size: 20g/piece; dumplings arrangement: 10kg/m2    ; packed in a plate for freezing.
    ◊Length of inlet & outlet and food passing height are adjustable according to different foods to be frozen.
