    NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing

    Ask Lasest Price
    Brand Name : SUMA
    Model Number : GF40
    Certification : ISO SGS
    Price : USD50-USD200 PER PIECE
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, Paypal
    Supply Ability : 1000PCS Per Month
    Delivery Time : 10-15 Days
    • Product Details
    • Company Profile

    NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing

    GF40 1115 Nm Conveyor One Way Roller Bearing


    Features


    The GF Series Freewheels are self centring. From size 8 to size 20, centring is steel on steel, whilst from size 25 to 130, centring is ensured by 2 160 series bearings.

    Torque foreces are transmitted from the shaft to the inner race by means of a keyway and from the outer race to the seat by means of front pullers.

    Shaft tolearances must be either h6 or j6, seating tolearances must be H7 or G7.

    If no front pullers are used, the seating tolearance becomes K6.


    Before being put onto service, the freewheels must be lubricated with suitable lubricants . Oil lubrication is essential when a high number of rotations in neutral is reached .


    Dimensions and Capacities

    TypedH7Dn6LsD1D2btWeightInner ringOuter ringTKNDrag torque
    freewheels/freewheels/
    mmmmmmmmmmmmmmmmKgoverruns min-1overruns min-1NmNcm
    GF 88372012030630.110001000200.09
    GF 99372012030630.110001000200.09
    GF 1212372012030630.110001000200.11
    GF 151547301263773.50.3900900780.15
    GF 202062361375283.50.67007001880.18
    GF 25258040-4068941.2210036002500.36
    GF 30309048-45751251.8170032005000.4
    GF 353510053-50801362.4150030006800.6
    GF 404011063-55901573.31200260011150.84
    GF 454512063-609516741000240015000.94
    GF 505013080-70110178.55.7800210023751.28
    GF 555514080-751151896.5750200025001.5
    GF 606015095-801251898.9650190042501.6
    GF 7070170110-9514020913.5550180058753.6
    GF 8080190125-110160209195001600100003.6
    GF 9090215140-1201802411.527.24501400173506.8
    GF 100100260150-1402102814.544.53501300197508.8
    GF 130130300180-1602403217.56825010003500012.5

    Pictures


    Package :


    Quality NFR40 GF40 1115 Nm Conveyor One Way Freewheel Roller Bearing for sale
