    1W RF Amplifier Mini Size High Efficiency

    Introduction


    The ESCW-4326 is a COFDM RF power amplifier featuring mini size, high linearity and high reliability. It is available for 0.37dBm (27dBm), 1W (30dBm) and 2W (33dBm), frequency 300MHz-2700MHz.


    Features


    • High linearity, high reliability, anti-open circuit and short circuit
    • Brushed surface, natural conductive oxidation; pure aluminum material, good heat dissipation, full metal shielding structure
    • Wide voltage 12~18V, especially suitable for professional UAV transmitter
    • Mini size: 43×26×12mm
    • RF connector: SMA or MCX
    • High gain 35dB, easy to connect with modulators with weak output signals

    Specification


    • Frequency Range: Any 30MHz from 300~2700MHz (50, 100MHz or 500MHz is also available, but the wider the range, the lower the efficiency)
    • Digital Linear Power: ≥0.37dBm
    • ACPR: ≥30 dBc
    • Gain: ≥35dB
    • In-band Flatness: <0.5dB (typically<0.25dB);
    • Power Supply Voltage: 12~18V (built-in low dropout voltage regulator chip, minimum voltage difference 0.3~0.4V)
    • Working Temperature: -25~+55℃
    • Storage Temperature: -45~+65℃
    • Dimensions: 43×26×12mm (0.37dBm, 1W, 2W)
    • Cooling Method: External Radiator
