    AS2027 15mm Boltless High Cr Cement Mill Wave Liner Plates

    Ask Lasest Price
    Brand Name : Eternal Bliss
    Model Number : EB2080
    Certification : ISO9001:2008
    Price : USD 2.0~4.5/kg
    Payment Terms : By T/T or L/C
    Supply Ability : 10000 Tons Per Year
    Delivery Time : It depends on the quantity to be ordered.
    • Product Details
    • Company Profile

    AS2027 15mm Boltless High Cr Cement Mill Wave Liner Plates


    Boltless Coal Mill Cylinder Liner High Cr Boltless Wave Liner Plates



    Product Description:

    1. Material: high chromium cast iron;


    2. Wear plate thickness: 15mm, 20mm, 15mm, 30mm, 32mm, 40mm, 50mm, 60mm, 80mm, 100mm, 200mm, 500mm, 1000mm, etc., customized by customers;


    3. Shape: flat, curved, corrugated, etc., customized by customers;


    The sand casting process is used to produce high-chromium cast iron wear-resistant liners. Do quenching and tempering treatment to achieve better wear performance.


    Eqv. Standards

    Nominal Chemical Composition (W%)

    C

    Si

    Mn

    Ni

    Cr

    Mo

    Cu

    P

    S

    EN-GJN-HV600(XCr11)

    ASTM A532 12% Cr

    1.8-3.6

    ≤1.0

    0.5-1.5

    ≤2.0

    11.0-14.0

    ≤3.0

    ≤1.2

    ≤0.08

    ≤0.08

    EN-GJN-HV600(XCr14)

    ASTM A532 15% Cr-Mo

    AS 2027 CrMo 15 3

    G-X 300 CrMoNi 15 2 1

    1.8-3.6

    ≤1.0

    0.5-1.5

    ≤2.0

    14.0-18.0

    ≤3.0

    ≤1.2

    ≤0.08

    ≤0.08

    EN-GJN-HV600(XCr18)

    ASTM A532 20% Cr-Mo

    AS 2027 CrMo 20 1

    G-X 260 CrMoNi 20 2 1

    1.8-3.6

    ≤1.0

    0.5-1.5

    ≤2.0

    18.0-23.0

    ≤3.0

    ≤1.2

    ≤0.08

    ≤0.08

    EN-GJN-HV600(XCr23)

    ASTM A532 25% Cr-Mo

    AS 2027 Cr27 LC & Cr27 HC

    G-X 260 Cr27

    1.8-3.6

    ≤1.0

    0.5-2.0

    ≤2.0

    23.0-30.0

    ≤3.0

    ≤1.2

    ≤0.08

    ≤0.08

    AS 2027 Cr35

    3.0-5.5

    ≤1.0

    1.0-3.0

    ≤1.0

    30.0-40.0

    ≤1.5

    ≤1.2

    ≤0.06

    ≤0.06

    AS 2027 CrMoCu 20 2 1

    2.6-2.9

    ≤1.0

    ≤1.0

    ≤1.0

    18.0-21.0

    1.4-2.0

    0.8-1.2

    ≤0.06

    ≤0.06


    Product Details:
