Structural Steel Plate EN10025-4 S355J2+N Alloy Steel Plate EN
10025 S355J2G3
S355J2 steel is a kind of common carbon steel material. We also
call S355J2 steel as common structural steel. The equal material of
S355J2 steel are : DIN-ST52-3, JIS-SS540, ASTM - A572GR60. The
standard of S355J2 is EN 10025.
EN 10025 S355J2 steel material can be produced into S355J2 steel
sheet, S355J2 steel plate ,S355J2 steel pipe , S355J2 steel sheet
bar and S355J2 profile steel.
S355J2 is a kind of hot rolled steel. The rolling way for it are :
HR, AR, CR, N, TMCP
The heat treatment suitable for S355J2 steel are : N, T, A, Q&T
Size range for S355J2 steel plate is : 2-580mm * 1000-3800mm *
3000-18000mm
Size range for S355J2 steel pipe is : 10-4220mm * 2-80mm
Size range for S355J2 hot rolled steel round bar is : 10-200mm
Size range for S355J2 hot forged steel round bar is : 200-600mm
S355 offers high yield and tensile strength and is supplied with a
variety of treatments and test options to ensure it is a highly
usable steel in your various projects.
EN 10025-2 S355J2 High Yield Strength Structural Steel Plate
S355J2+N and S355J2G3 are the same steel grades as both grades
delivery condition are normalized. G3 and N stand for normalized.
S symbol for Structural Steel
JR symbol 20 temperature impact test
J0 syambol 0 temperature impact test
J2 symbol -20 temperature impact test
S355J2 Characteristic
S355J2 is a low carbon, high tensile strength structural steel
which can be readily welded to other weldable steel. With its low
carbon equivalent, it possesses good coldforming properties. The
plate is produced by fully killed steel process and supplied in
normalized or controlled rolling condition.
S355J2 Application
Structural application in freight cars, transmission towers, dump
trucks, cranes, trailers, bull dozers, excavators, forestry
machines, railway wagons, dolphins, penstocks, pipes, highway
bridges, building structures, oil and gas platforms, offshore
structures, shipbuilding, power plant, palm oil equipments and
machineries, fans, pumps, lifting equipments and port equipments.
Dimension we could supply:
Thickness 8mm-300mm, Width: 1500-4020mm, Length: 3000-27000mm
S355J2 Delivery Condition: Hot rolled, CR, Normalized, Quenched,
Tempering, Q+T, N+T, TMCP, Z15, Z25, Z35
S355J2 Chemical Composition(max %):
| Chemical Composition | C.E. |
| C | Si | Mn | Cr | Mo | Ni | V | W | S | P | CU |
10025-2:2004 S355J2 | max 0.22 | max 0.55 | max 1.60 | - | - | - | - | - | max 0.035 | max 0.035 | - | max 0.047 |
S355J2+N Mechanical Properties:
| Thickness (mm) | Yield Strength Reh min (N / mm²) | Tensile Strength Rm min (N / mm²) | Elongation A5 min (%) | Impact Values Charpy-V-Notch Longitudinal Average from 3 Speimens Thk. >10<150mm. |
| 3<thk<100 | 315-335 | 490-630 | max 22 | 27 Joules at -20 C |
mittel is specialized in low alloy high strength structural steel,
mainly dealing with specification standard plates in EN 10025-2, EN
10025-3, EN 10025-4, EN 10025-6, ASTM A633, ASTM A573, ASTM A572,
DIN 17100, JIS G3106, ASTM A709, ASTM A283, ASTM A529, ASTM A656,
EN 10225, ISO 630, NFA 35-501, and so on, the thickness up to
300mm.
