    TH629 DMR Two Way Radio with Single Frequency Repeater Support & Excera Easy Trunk

    Ask Lasest Price
    Brand Name : Suntor
    Model Number : TH629
    Certification : CE RoHS SGS FCC
    Price : negotiation
    Payment Terms : T/T, Western Union, PayPal
    Supply Ability : 1000SET/Month
    Delivery Time : 3-7days
    • Product Details
    • Company Profile

    TH629 DMR Two Way Radio with Single Frequency Repeater Support & Excera Easy Trunk

    TH629 DMR Two Way Radio with Single Frequency Repeater Support & Excera Easy Trunk


    TH629 DMR Radio Specifications-v1.0_compressed.pdf...


    Product Features:


    • Utilise TI OMAP Processor, Not RDA low tier IC;

    • Fully Compliant with CE and FCC Certification;

    • IP68 Standard Compliance;

    • Built-in GPS,Bluetooth and Mandown;

    • Fast charge, 85% of battery capacity finished within one hour;

    • DMR Multi-Site IP Connection;

    • DMRA ARC4/DES/AES Encryption;

    • Single Frequency Repeater Support

    • Excera Easy Trunk Support;

    • DMR T3 & MPT 1327 Support Capability;

    • Ultra High Cost Effective;

    • Glonass Support;



    General
    Frequency Bands

    VHF: 136-174MHz

    UHF1: 400-470MHz UHF3: 350-400MHz

    Channel Capacity1024
    Channel Space12.5/20/25KHz
    Dimensions(H*W*D)115*54*28mm
    Weight278g (With standard battery and antenna)
    Operating VoltageDC 7.4V
    Battery

    2000mAh Li-ion

    2400mAh Li-ion

    Working Time

    (2000mAh,5-5-90 mode)

    Analog:11H (No GPS)

    Digital:14H (No GPS)

    Transmitter
    Frequency Stability0.5ppm
    RF Power Output

    VHF: High 5W Low:1W

    UHF: High 4W Low:1W

    Digital Modulation

    7K60FXD (Data Only)

    7K60FXW (Data and Voice)

    Analog Modulation16K¢F3E @ 25KHz /11K¢F3E @ 12.5KHz
    4FSK Modulation Accuracy5%
    4FSK TX BER0%
    4FSK and Magnitude Error5%/1%
    Adjacent Channel Power70dB @ 25/20 KHz / 60dB @12.5 KHz
    Conducted and Radiated Emission-36dBm <1GHz / -30dBm >1GHz
    Transmission Deviation limits5KHz@25KHz/4KHz@20KHZ/2.5KHz@12.5KHz
    Audio Distortion3%
    Hum and Noise45dB @ 25KHz/ 43dB @ 20KHz/ 40dB@12.5KHz
    Audio Response+1dB ~ -3dB
    Receiver
    Digital Sensitivity

    -120dBm / BER 5%

    -116dBm / BER 1%

    Digital Dynamic Faded Sensitivity

    (100KM/H& 8KM/H Rayleigh Fading)

    -104dBm
    Analog Sensitivity-120dBm / 12dB SINAD
    Intermodulation70dB (TIA603) 65dB (ETSI)
    Blocking90dB (TIA603 & ETSI)
    Spurious Response Rejection70dB (TIA603 & ETSI)
    Adjacent Channel Selectivity

    70dB@25 & 20KHz (ETSI)

    60dB@12.5 KHz (ETSI)

    Conducted Spurious Emission-57dBm
    Rated Audio Power Output0.5W
    Rated Audio Distortion3%
    Hum and Noise45dB @25KHz/43dB@20KHz/40dB@12.5KHz
    Audio Response+1 ~-3dB
    Digital Vocoder TypeAMBE++
    Digital ProtocalETSI-TS102 361 -1, -2,-3
    Reliability
    Operating Temperature-30 ~ +60℃
    Storage Temperature-40 ~ +85℃
    IP Rating/HumidityIP68 (IEC60529)
    Shock & VibrationPer MIL-STD-810 C/D/E/F/G Standard
    ESD

    IEC 61000-4-2(level 4)

    ±8KV(Contact) ±15KV (Air)

    GPS
    TIFF Cold Start<60s
    TIFF Hot Start<10s
    Horizontal Positioning Accuracy<9m
