    Firestone W01-358-6932 2B9-246 Goodyear Air Spring

    Ask Lasest Price
    Brand Name : Goodyear
    Model Number : 2B9-246
    Certification : ISO/TS16949:2009
    Payment Terms : T/T, Western Union,Paypal or Others
    Supply Ability : 1000pcs/week
    Delivery Time : 2-8 work days
    • Product Details
    • Company Profile

    Firestone W01-358-6932 2B9-246 Goodyear Air Spring

    2B9-246 Goodyear Air Spring Firestone Double Air Bags W01-358-6932 For TRP AS69320



    OEM Original Equipment Manufacturer:


    AUTOMANN
    ABSP2B12R-6932


    TRIANGLE

    4452


    CONTI
    64514

    FD 200-19 452


    TRP

    AS69320


    FIRESTONE
    6932

    W013586932


    RIDEWELL
    1003586932C


    ReferenceOEM
    GUOMAT NO.2B6932
    Firestone

    W01-358-6932 /

    W013586932 /

    W01 358 6932

    Contitech

    FD 200-19 452 /

    FD200 19 452 /

    FD 20019 452

    Goodyear

    2B9-246 /

    2B9246 /

    2B9 246

    Ridewell1003586932C

    Specifications and Technical Data of 2B9-246 Goodyear


    Compressed Height: 3.12 / 79mm

    Top Cover Plate Diameter: 6.31 inches / 160mm

    Bottom Cover Plate Diameter: 6.31 inches / 160mm

    Screw Center Distance : 89 mm

    Distance Gas Hole Between Nut :in the middle of the plate

    Top Cover Plate Screw (Nut) Tooth : 1pcsX1/2-12UNC

    Bottom Cover Plate Screw (Nut) Tooth : 1pcsX 1/2-16UNC

    Rubber Bellows MAX Diameter: 251 mm

    Rubber Bellows Natural Diameter 224 mm

    The Working Stroke : MAX 274 mm to MIN 95 mm

    Gas Hole / Air inlet : 1/4 NPTF

    Firestone Bellows Number:20
