    862MHz 1550nm 5dBm CATV Optical Transmitter

    Ask Lasest Price
    Brand Name : Yogel
    Model Number : YG-1550DMTX Series
    Certification : ISO9001
    Payment Terms : L/C, , T/T, Western Union
    Supply Ability : 5000pcs/month
    Delivery Time : 3-7days
    • Product Details
    • Company Profile

    862MHz 1550nm 5dBm CATV Optical Transmitter

    CATV Optical Equipments Fiber Optic 1550nm Direct Modulation Optical Transmitter
    Features
    * With two kinds of structure optional: Optical output port in front panel or Optical output port in back Panel, 19”1U Rack, advanced Aluminum Shell.
    * Working Bandwidth:47~862MHz (1000MHz optional).
    * 1310nm optical transmitter (2-18mw) adopt Fujitsu laser from Japan, while (20-30mw) adopt ORTEL laser from USA.
    * Stable temperature Circuit (ATC) and Optical output power circuit (APC) can make sure best working status of laser.
    * Working status indicator in front panel and RF testing port in back panel.
    Standard Configruration
    * Single power supply module
    * With SNMP
    * RF input port: Inch screw thread (British system), Optical output port: SC/APC connector
    * Package Material: Cartoon
    * Package Information:
    1U Volume(L*W*H): 595*490*120mm Weight: 4.50KG 1 pieces/cartoon
    1U Volume(L*W*H): 595*490*240mm Weight: 9.00KG 2 pieces/cartoon
    Ordering Information
    * Power Supply: 220V, 110V, 48V & EURO, USA, CHN standard etc. (optional)
    * Optical Connector: SC/APC, FC/APC, LC/APC, etc. (optional)
    * RF input port: Metric system, British system (optional)
    * How many output ports& output optical power of each port (See below)
    Ordering Guider
    Name
    Model No.
    Output Optical Power
    Max≤25KM
    Max≤35KM
    YG-1550DMTX-3-25/35
    3dBm
    YG-1550DMTX-5-25/35
    5dBm
    YG-1550DMTX-7-25/35
    7dBm
    YG-1550DMTX-9-25/35
    9dBm
    YG-1550DMTX-10-25/35
    10dBm
    Add Additional Functionality
    Add Power Supply Module
