Decorative Round Hole Perforated Sheet Metal Mesh
1.Material: Low carbon steel plate, stainless steel plate, copper plate,
nickel plate. stainless steel plate, aluminum, hot and cold steel,
copper and fiber, plastic sheeting and other non-metallic plate.
2.Hole size: 0.8--18mm
3.Thickness: 0.2-10mm
4.Weaving: Stamping made
5.Features: Flat surface, smooth, beautiful, strong and durable, wide
application.
6.Specifications: Coil sheet 1X20m, flat sheet 1X2m.
7.Hole Patterns including: Round; Rectangular hole; Square; Triangle; Diamond; Hexagonal;
Cross; Slotted; and other patterns according to your drawings or
application requirement.
Processing: Punching
8.Uses: Mining, medicine, grain selection, indoor sound insulation,
silencers, ventilation, grain storage and machine protection
Uses:perforated sheet is widely used in the core of
filter,medicine,filtering,breeding,battery,mechanical protecting.
Specifications,
Plate
Material | Thickness of
Metal (mm) | Hole
Dia. (mm) | Pitch
(mm) | Sheet
Width (m) | Sheet
Length (m) | Porosity
(%) | Weight
(kg/m2) |
Rolling
plate | 0.2 | 6 | 2 | 1 | 20 | 44 | 0.88 |
| 0.35 | 5 | 4 | 1 | 20 | 24 | 2 |
| 0.45 | 6 | 3 | 1 | 20 | 35 | 2.5 |
| 0.8 | 3 | 3 | 1 | 20 | 19.6 | 3 |
| Flat plate | 0.5 | 1 | 1 | 1 | 2 | 19.6 | 3.14 |
| 0.55 | 1.1 | 2.2 | 1 | 2 | 22.67 | 3.411 |
| 0.55 | 1.5 | 2.8 | 1 | 2 | 26.03 | 3.268 |
| 0.8 | 1.5 | 1.5 | 1 | 2 | 19.6 | 5 |
| 0.8 | 2.0 | 3.4 | 1 | 2 | 30.78 | 4.465 |
| 1.5 | 2 | 2 | 1 | 2 | 19.6 | 9.4 |
| 1.5 | 5.0 | 8.0 | 1 | 2 | 35.39 | 7.843 |
| 3 | 5 | 16 | 1 | 2 | 19.6 | 18.8 |
Stainless
steel plate | 0.5 | 1 | 1 | 1 | 2 | 19.6 | 3.14 |
| 0.8 | 1.5 | 1.5 | 1 | 2 | 19.6 | 5 |
| 1 | 2 | 2 | 1 | 2 | 19.6 | 6.28 |
| 2 | 5 | 16 | 1 | 2 | 19.6 | 6.28 |
Aluminum
plate | 0.5 | 1 | 1 | 1 | 2 | 19.6 | 1.08 |
| 0.8 | 3 | 3 | 1 | 2 | 19.6 | 1.72 |
| 1.6 | 2 | 2 | 1 | 2 | 19.6 | 3.24 |
| 3 | 4 | 16 | 1 | 2 | 19.6 | |
Advantage:
1. Attractive appearance
2. Easy installation
3. Light weight
4. Durable
5. Can be readily formed
6. Uniform sound abatement
7. Largest selection of hole size patterns and configurations
Application
Mining, medicine, food selection, indoor noise, silencers and grain
storage ventilation, mechanical protection, road,railway, resident,
machines, electical equipment for protecting and isolating.
Hole shape: Round hole, square hole, long round hole, triangle
hole, scale hole, diamond hole, oval hole, hexagonal hole, slot
hole, and so on.
Packing
1. wrapped with plastic paper, then in cartons or pallet.
2. Other special packages according to customers' requirements.
