1756-RM2 1756RM2 AB AB ControlLogix Redundancy Enhanced Module
⇒ Click here for good price 1756-RM2
| Brand/Manufacturer | AB/USA |
| Part Number | 1756-RM2 |
| Alternate Part Number | 1756-RM2 |
| Description | MOTOR SERVO |
| Dimennsions | 23.3x18.2x5.3cm |
| Weight | 0.4kg |
Contact Us
Email: miya@mvme.cn (CLICK)
QQ: 2851195450
Tel: 86-18020776792(CLICK)
Skype:miyazheng520(CLICK)
Product Details
The 1756-RM2 is a ControlLogix Enhanced Redundancy Module
manufactured by Allen Bradley. The 1756-RM2 features an enhanced
speed with a performance of 1000 Megabytes per Second. Paired with
1756-L7 x controllers in both chassis, the 1756-RM2 gives best scan
performance and for cross loading the 1756-RM2 uses redundant fiber
ports ensuring no single point of failure. While on channel
switchover, the processing chassis is usually synched while scan
time might encounter delay of up to 10 Milliseconds. The 1756-RM2
comes with enhanced safety features making it interference free.
The 1756-RM2 is a redundancy module that draws a 1.16 Amps current
running at 5.1 Volts DC and 3.4 mA at 24 Volts DC. The maximum
power dissipation for the 1756-RM2 is 6 Watts with a thermal
dissipation of 21 BTU per hour and it is usually installed on any
slot location on the chassis. The shipping weight for the 1756-RM2
is 0.64 pounds and the shipping dimensions for the 1756-RM2
includes 5.51 x 4.41 x 5.71 inches. The module comes with an open
enclosure. For communication, the 1756-RM2 features seven enhanced
ControlNet and EtherNet/IP communication modules. When it comes to
wiring, the 1756-RM2 functions effectively with the 1756-RMC1, the
1756-RMC3, and the 1756-RMC10 cables with 1 meter, 3 meter, and 10
meter lengths respectively.
The 1756-RM2 also supports the ControlLogix 5560 and ControlLogix
5570 series of controllers while the redundant system must have two
1756 Chassis featuring similar number of slots, modules, and also
the firmware version. The operating temperature for the 1756-RM2 is
32 to 140 degrees Fahrenheit which is equivalent to 0 to 60 degrees
Celsius. For operating the module, RSLinx 2.59.01 communication
software and the RSLogix 5000 20.01.00 programming software are
required.
