65W Centrifugal Blower Fan Exhaust Centrifugal Blower Quiet Centrifugal Fan

Ask Lasest Price
Brand Name :	CPMDJ
Model Number :	YYS-65-4
Certification :	CCC
Price :	Negotiable
Payment Terms :	TT, LC
Supply Ability :	10000000
Delivery Time :	15-35 days

Add to Cart

Product Details
Company Profile

65W Centrifugal Blower Fan Exhaust Centrifugal Blower Quiet Centrifugal Fan

65W Centrifugal Blower Fan Exhaust Centrifugal Blower Quiet Centrifugal Fan

Centrifugal Blower fan with high efficiency, low power consumption, large air value and quiet noise level.Available with global voltage input accommodating 100VAC to 240VAC, allowing for a single model to be used in products for both 115VAC and 230VAC applications.

Storage temperature range : -40~+80 C°

Operating temperature range : -40~ +70C°

Bearing type : ball bearing NMB or other equivalent brand

Life time : above 35000hours

Specification:

Fan model	Motor model	Voltage	Frequency	Speed	Air volume	Current	Capacitor
CPZ7-7	YDK90-6	203V-240V	50/60Hz	850RPM	1000m³/h	0.9A	5μF
CPZ7-7	YDK200-4	203V-240V	50/60Hz	1150RPM	1500m³/h	1.8A	10μF
CPZ8-8	YDK200-6	203V-240V	50/60Hz	820RPM	2000m³/h	2.0A	10μF
CPZ8-8	YDK300-4	203V-240V	50/60Hz	1200RPM	2200m³/h	2.1A	10μF
CPZ9-9	YDK250-6	203V-240V	50/60Hz	850RPM	2000m³/h	1.9A	10μF
	YDK375-6	203V-240V	50/60Hz	850RPM	2000m³/h	3.5A	10μF
	YDK375-4	203V-240V	50/60Hz	1200RPM	2500m³/h	3.5A	10μF
	YDK550-4	203V-240V	50/60Hz	1150RPM	3250m³/h	4.6A	20μF
CPZ10-10	YDK450-6	203V-240V	50/60Hz	850RPM	3000m³/h	3.5A	20μF
CPZ10-10	YDK550-4	203V-240V	50/60Hz	1150RPM	3250m³/h	4.6A	20μF
CPZ12-9	YDK750-6	203V-240V	50/60Hz	830RPM	3000m³/h	7.2A	30μF
CPZ12-9	YDK900-4	203V-240V	50/60Hz	1250RPM	6000m³/h	8.0A	30μF
CPZ12-12	YDK750-6	203V-240V	50/60Hz	830RPM	3000m³/h	7.2A	30μF
CPZ12-12	YDK900-6	203V-240V	50/60Hz	880RPM	7000m³/h	8.6A	30μF

The radial / centrifugal fans have an impeller as the moving component; it is nothing but a set of blades or ribs suitably placed around a central shaft. They are also sometimes called a squirrel cage or a scroll fan.

In centrifugal fans, the air flows at right angles to the inlet air direction and throws the air outward toward the outlet through the action of deflection and centrifugal force. When the impeller rotates, air is allowed to enter the fan around the open space between the impeller and the shaft and is forced to proceed at a right angle to the shaft toward the opening of the fan casing. This type of fan produces, comparatively (with respect to axial fans), a higher pressure and less gas flow; they are noisier than axial fans. Radial/centrifugal fans also are classified according to their type of wheel blades.

Certificate of HVAC Air Cooling Motor:

Our Service of HVAC Air Cooling Motor:

● Online service: we can talk on Trade manger , Email, Phone, Wechat and so on.
● Customer service: we accept OEM,with your own design, brand and label.
● Sample service:we will send samples for free, if you decide to buy our product
● Presale service: We will try our best to answer you every question in time.

● In-sale service: We will produce the goods with high quality; and pack carefully. We will also keep contact with you when the goods are ready for delivery until it reached safely.

● After-sale service:If you have any question, please contact us at any time.
