5ml Anal And Vaginal Suppository Filling And Sealing Machine

Suppository Filling Sealing Machine Anal And Vaginal Suppository Machine

Products Description:
Automatic suppository filling production line has a stable and efficient manufacturing process, filling, freezing, sealing and
other production processes to complete the whole process, and the production capacity is 8000-12000grain/hour.

Product Details:

Working Principle:
1.Thermoforming:
Put the roll of packaging material(PVC,PVC/PE)into the molding area through the clamping mechanism.→Preheat the mold→Heat the Mould→Forming→Blowing→Blow bubbles.
Triangle knife trimming process (cut bottom)→Cut dashed line (torn line).
2.Filling:
Embedded filling can achieve one-time filling of the molded suppository with a filling accuracy of ± 2%.The filling bucket has an electric heating and heating preservation system. A stirring motor is on the top of it which can make the drug in a uniform state. The drug in the bucket will enter into the filling head through a high-precision filling pump. After the filling, the remaining drug is circulated through the other end to the raw material bucket and then used in the next filling.
3.Cooling:
The entire row of filled suppository are put into the cooling box. The outside of the cooling box is equipped with chillers. The cooling air cools the suppositories in the cooling box through the condenser in the cooling box.
4.Sealing and Cutting:
The cooled suppository which is in solid form enters the sealing area:Preheating mold(preheating)→Sealing mold(sealing)→Coding mold(batch number)→Hobs(trim on top)→Count and cut(And then to shear a set of finished product for 5 and 6 grain (be) according to customer's requirements).
