55 Inch FHD TFT - LCD DID Video Wall Solutions Narrow Bezel 700nits
Monitor Screen
1. DID video wall give a large and exciting viewing experience, communicate with viewer more effectively every moment of the day.
2.Genevison DID video wall ultra-thin bezel design deliver a
maximum visual impact for all Digital Signage and Conference
Collaboration Applications.
3.With energy-saving LED Technology that enables 24hr a day
operation, and Auto Standby for Image Burn Protection offer
premium, reliable performance to meet all your commercial
application demands.
4. Narrow bezel of 5.5mm and high brightness of 700nits ensure a
vivid viewing experience.
This DID video wall system is widely used in meeting room,
conforence room, educational institute, shopping mall as well as
CCTV monitoring location
- DID technology is a high quality image representative of audio and
video serial transmission, the product supports audio embedded solution and a variety of signal ports.
- Built-in splicing module, support splicing screen function and
creating one window(PIP) across the screen,roaming
service,scaling,PIP, matrix joint control.
- Unique DNX motion supplement image processing technology ensure
dynamic image without motion trail.
- Have splicing image processing RS-232(RJ-45)loop-circuit
input/output.
Technical Parameters:
Specification/Model | MD-550 |
Panel Size | 55" LCD-DID |
Screen Aspect Ratio | 16:9 |
Visual Angle | Horizontal 178/Vertical178 |
Brightness | 700cd/sqm |
Contract Ratio | 5000:1 |
Resolution Ratio | 1920*1080 |
Color Components | 16.7M |
Response Time | 8ms |
Power Consumption of Stand-alone | 260W |
Power Supply | Input:AC110-220V-50/60Hz |
Service Life of Panel | 60000Hours |
Dimension of Machine Frame(±1mm) | (Width)1020.88mm*(Height)575.49mm |
Size of Shell Frame(±1mm) | Left /right side2.8mm/top/bottom2.8mm |
Panel Display Area | (Width)1018.08mm*(Height)572.69mm |
Shell Color | Black |
Installation | Wall-mounted or built-in a floorstanding cabinet |
Net Weight(approximate) | 27.5kg |
Working Humidity | 10%-90% |
Working Temp. | 0-60 Celsius degree |
Input Port | 3*BNC, 1*VGA, 1*DVI,1* |
VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 |
Resolution Ratio | 480I,480P,576I,720P,1080I,1080P |
Output Port | 1 Video output(BNC) |
Split Screen/PIP Mode | Two signals image or PIP |
Splice Function | Multiscreen Splice Function(image processing Function) |
Competitive Advantage:
Digital information display with LCD-DID Industrial
HD&High-brightness narrow edge LCD.Built-in splicing
module, Support splice function,support Creating one window(PIP)
across the screen,roaming service,
scaling,PIP Support matrix joint control.
Unique DNX motion supplement image processing technology, Dynamic
image without motion trail,Splicing
image processing RS-232(RJ-45)loop circuit input/output.,Input by
remote control with wire,mobile receiver
head.
Product View:
ow Bezel LCDVideo Walls
