14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector

    Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers

    Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers
    • Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers
    • Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers
    • Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers
    • Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers
    • Buy cheap 14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector from wholesalers

    14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector

    Ask Lasest Price
    Brand Name : FUYCONN
    Model Number : FUYSC079-2 (14P)
    Certification : ISO
    Price : USD0.2-USD2/pc
    Payment Terms : T/T, Paypal
    Supply Ability : 100000/ week
    Delivery Time : 5-8 works day
    • Product Details
    • Company Profile

    14Pin SCSI Connector CN Type PCB Right Angle Terminal Servo Connector

    Catalog: SCSI CONNECTOR.pdf


    Right Angle PCB 14 Pin SCSI Connector, 90 Degree PCB Mount CN Type 1.27mm Pitch 14pin Female SCSI Connector with R/A Terminal


    SCSI (Small Computer System Interface), is a kind of more special interface bus, equipped with a variety of types of peripherals to communicate. Advanced High Speed A versatile, high-speed, and low-cost method of interconnecting a varietyof computer peripherals and consume electronic devices.


    The SCSI Connector are 14pin, 20pin, 26pin, 36pin, 50pin, 68pin and 100pin, and PCB / IDC Crimping type SCSI Connector versions. The internal 100 pin SCSI connector has 100 pins arranged in two rows one on top of the other. The top row has 50 pins and the lower row has 50 pins.

    Product features

    No. of pin14pin
    shell :Stell, Nickel Plated
    Housing :PBT
    Contacts :Phosphor bronze
    Gold plating1U", 3U", 5U", 10U", 15U",30U"

    Electrical Specifications

    Current Rating1AMP
    Withstanding Voltage500v for one minute
    Insualtion Resistance500MΩ min (at DC500V)
    Contact Resistance35MΩ Max
    Operating temperature :-55°C to +105°C

    Technology Parameters


    Type: SCSI Connector

    Application:
    Servo
    Gender:
    Female
    Orientation:
    Right Angle
    Insulator material:
    PBT
    Contact Current Rating:
    1A AC/DC
    Contact Resistance:
    Max 35m ohm
    Insulator:
    PBT, glass-filled, UL94V-0 rated
    Contact:
    phosphor bronze
    Back shell:
    nickel-plated
    Insulation resistance:
    500MΩ (minimum)
    Contact resistance:
    35mΩ (maximum)
    No. of Pin :
    14pin 26pin 50pin
