Applications
1. Scientific instruments,such as providing constant temperature
source for Thermal conductivity measuring instrument, medical
equipment and optoelectronic components etc.
2. Maintaining proper working temperature in extreme environment,
such as satellites, aero equipment and instruments set in high
latitude regions, card reader, LCD etc.
3. Vacuum heating and baking.
4. Military industry, such as missiles, warships, tanks, radar.
5. Automobile rearview mirror.
6. Medical health and beauty instrument industry.
Flexible film platinum resistance
Platinum resistance PT100 or PT1000 chip is set in PI or silicone
rubber or PET insulation layer, which protect the heating part.
Features:
1. Thin and large contact area, sensitive temperature response;
2. Easy installation.
Applications:
Widely used in medical and electric fields, especially for surface
where space is limited.
Film temperature sensor
This type of heaters’ platinum resistance PT100 or PT1000 chip is
set in 0.1 mm PI insulation layer, which protect the heating part.
Features:
1. Thin and large contact area, sensitive temperature response;
2. Easy installation;
3. Large response area;
Application:
Widely used in medical and electric fields, especially for
irregular surface.
Instrument insulation tube
This type of product is widely used in assist heating instrument
tubes in petroleum, chemical, metallurgy and aviation industry,
especially for Gas analyzer.
Product Description
| ◊ Heat resistant temp. |
| continuous use temp. | 200°C(customized) |
| max. temp. | 250°C(customized) |
| ◊ Power characteristics |
| insulation resistance | 1000MΩ or over DC500V(customized) |
| withstand voltage | 1500V/1min(customized) |
| ◊ Size |
| max. | customized |
| min. | customized |
| thickness | customized |
