Cordierite high temperature resistant environmental protection
ceramic ring
Product Overview
Welded ceramic ring is a ring-shaped ceramic molten pool used to
protect the welding nail and the molten metal of the base material
from discharge after melting.
shear nails (also known as: welding nails, studs, studs)
accessories, used in conjunction with shear nails, usually using
professional stud welding machine welding. Used in conjunction with
professional welding machines, compared with manual arc welding,
the operation is simple, the skill requirements are not high, and
the damage of workers caused by arc light and smoke is reduced.
Product parameter table
| NO | P/N | D1+0.5 | D2(±1) | D3(±1) | H3(≈) | D2(≈) |
| PF6 | 90/00001 | 5.6 | 9.5 | 11.5 | 6.5 | 3.3 |
| PF8 | 90/00002 | 7.4 | 11.5 | 15 | 6.5 | 4.5 |
| PF10 | 90/00003 | 9.2 | 15 | 17.8 | 6.5 | 4.5 |
| PF12 | 90/00004 | 11.1 | 16.5 | 20 | 9 | 5.5 |
| PF16 | 90/00005 | 15.0 | 20 | 26 | 11 | 7 |
| PF20 | 90/00006 | 18.6 | 30.7 | 33.8 | 10 | 6 |
| PF24 | 90/00007 | 22.4 | 30.7 | 38.5 | 18.5 | 14 |
| NO | P/N | D1+0.5 | D2(±1) | D3(±1) | H3(≈) | D2(≈) |
| UF6 | 90/00008 | 6.2 | 9.5 | 11.5 | 8.7 | 4.7 |
| UF8 | 90/00009 | 8.2 | 11 | 15 | 8.7 | 4.7 |
| UF10 | 90/00010 | 10.2 | 15 | 17.8 | 10 | 5.2 |
| UF12 | 90/00011 | 12.2 | 16.5 | 20 | 10.7 | 6 |
| UF13 | 90/00012 | 13.1 | 20 | 22.2(26) | 11 | 6.5 |
| UF16 | 90/00013 | 16.3 | 26 | 30 | 13 | 8.5 |
| UF19 | 90/00014 | 19.4 | 26 | 30.8 | 16.7 | 12 |
| UF22 | 90/00015 | 22.8 | 30.7 | 39 | 16.6 | 14 |
| UF25 | 90/00016 | 26.0 | 35.6 | 41 | 21 | 16.5 |
Product advantages
The product is mixed and granulated with a variety of high
temperature resistant ceramic raw materials, which are formed by
compression and finally sintered by a high temperature tunnel kiln.
It has the characteristics of good stability, high refractoriness,
not easy to deform, and large mechanical strength.
Effect:
1. Prevent the welding of the welding torch and the components, and
damage the gun head;
2. Auxiliary melting of molten metal to make the welded joint more
beautiful.
Applications
It is widely used in manufacturing industries such as bridges,
shipbuilding, boilers, pressure vessels, steel structures, and auto
parts.
Product packaging
Carton packaging or according to customer needs
The company specializes in welding ceramic rings and supports
customization.
FAQ
1. Are you a businessman or a manufacturer?
We are a company, we have our own factory
2. How long is your delivery time?
Negotiable
3. Can the product be customized?
Can be customized
4. What is the product packaging?
Carton or according to customer requirements
