MINI VGA, + Audio TO HDMI,AV Signal Converter
1.0 INTRODUCTION
This kind of the Converter is a VGA video and audio converter. It
converts VGA input and audio into HDMI to allow PC users to show
their image not only on the PC’s monitor, but could also on TV, to
have a large display. The conversion is along with the audio.
Converter offers solutions for digital entertainment center, HDTV
retail and show site, HDTV, STB, DVD and Projector factory, noise
space and security concerns, data center control, information
distribution, conference room presentation, school and corporate
training environments.
2.0 SPECIFICATIONS
| Input port | 1xVGA,1xAudio |
| Output ports | HDMI A TYPE |
| Dimensions (mm) | 60.5(L) x55(W) x20(H) |
| Wight (g) | 40 |
| HDMI output | Max 1080P@60Hz,720p/60Hz.
|
| VGA input | Max 1080p@60Hz |
3.0 FEATURES
1. Support Max VGA 1080p@60Hz or 1920x1200 input;
2. Provide advanced signal processing with great precision,colors,
resolutions, and details;
3. No need to install drivers, portable, flexible, plug and play;
4. Support HDMI 1080P or 720p output；
5.No power supply, USB-powered mode.
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
1. Main unit (VGA TO HDMI Converter)-------------1PCS
2. USB Cable or 5V 1A Power adapter--------------1PCS
3. User Manual---------------------------------------------1PCS
5.0 PANEL DESCRIPTIONS
Please study the panel drawings below and become familiar with the
signal input(s), output(s) and power requirements.
1. VGA ---------------------------------VGA input
2. Audio ------------------------------Audio input
3. HDMI --------------------HDMI signal output
4. USB POWER ------------USB power input
6.0 CONNECTION DIAGRAM
