    12V 2A 24V 1A AC Adapter & 9V Charger (UL/IEC 60601, US Plug) – Ideal for Portable Ultrasound Diagnostic Devices

    Ask Lasest Price
    Brand Name : ANENpower
    Model Number : APM19U
    Certification : UL/cUL 60601-1, TUV EN 60601-1, CB IEC 60601-1, FCC, CE, PSE, UKCA
    Price : Please contact our Sales
    Payment Terms : 50% deposit, 50% before dispatch
    Supply Ability : 500,000.00pcs/month
    Delivery Time : 18~25 working days after receiving the deposit
    • Product Details
    • Company Profile

    12V 2A 24V 1A AC Adapter & 9V Charger (UL/IEC 60601, US Plug) – Ideal for Portable Ultrasound Diagnostic Devices

    UL 60601 Certified Medical Power Adapter 12V 2A 24V 1A 9V US Plug for Portable Ultrasound Diagnostic Equipment Devices


    UL/IEC 60601 certified medical-grade power adapter delivering triple output configuration: 12V 2A, 24V 1A, and 9V charging with US plug compatibility specifically engineered for portable ultrasound diagnostic systems. This hospital-grade power supply features medical isolation barriers, over-voltage protection, and electromagnetic compatibility to ensure uninterrupted imaging performance in clinical environments. Designed for radiology departments, emergency medical services, and point-of-care diagnostics, the adapter provides stable power for ultrasound probes, transducers, and imaging units requiring certified safety standards. Built with thermal protection and precise voltage regulation to maintain image quality and diagnostic accuracy during critical examinations, this FCC-certified adapter meets stringent medical safety requirements for professional healthcare use where reliable power directly impacts patient diagnostics and clinical outcomes.


    • Power Range: 15~24W

    • Universal AC Input 100~240 VAC
    • Frequency: 50~60Hz
    • AC Plug type: U:USA, E:EU, K:UK, A: AU
    • Output voltage available from 5~48 VDC

    • 2 x MOPP Compliance, IEC/EN60601-1 Approval
    • LPS Compliance
    • Protections: Short circuit / Over voltage / Over current
    • Energy Efficiency Level VI
    • No Load Power Consumption ≤ 0.1W
    • MTBF > 100,000 hours
    • Safety: UL/cUL, UL60601, TUV EN60601, CB 60601, CE, FCC
    • All models meet RoHS and WEEE
    • Dimension(L x W x H): 66.5L x 26W x 45.5H(mm)
    • Weight: 120g


    Model NO.MAX OUTPUT POWEROUTPUT VOLTAGEMIN LOADMAX LOADLOAD REGULATIONLINE REGULATIONRIPPLE & NOISE
    APM19UA15W5-8V0A3.0A±5%±1%100mV
    APM19UB20W9-13V0A2.0A±5%±1%180mV
    APM19UC20W14-19V0A1.42A±5%±1%200mV
    APM19UD20W20-27V0A1.0A±5%±1%250mV
    APM19UE20W28-35V0A0.71A±5%±1%280mV
    APM19UF20W36-48V0A0.55A±5%±1%360mV
    APM19UG18W5-8V0A3.0A±5%±1%100mV
    APM19UH24W9-13V0A2.0A±5%±1%180mV
    APM19UJ24W14-19V0A1.71A±5%±1%200mV
    APM19UK24W20-27V0A1.2A±5%±1%250mV
    APM19UL24W28-35V0A0.85A±5%±1%280mV
    APM19UM24W36-48V0A0.66A±5%±1%360mV
    NOTED:
    1 : Ripple & Noise is measured by using 20MHz bandwidth limited oscilloscope and terminated each output with a 0.1uF ceramic capacitor & parallel with 47uF aluminum capacitor at full load and nominal line.
    2 : Line regulation is defined by changing ±10% of input voltage from nominal line at rated load.
    3 : Max. Power (W) = Vo x Io
