    Electronic Components 4-Channel Single ADC SAR 500ksps 16-bit Parallel/Serial 48-Pin LQFP AD7654ASTZ Integrated Circuits

    Ask Lasest Price
    Brand Name : Analog Devices
    Model Number : AD7654ASTZ
    Certification : Original Part
    Price : to be Negotiated
    Payment Terms : T/T, Western Union, Paypal, Wechat Pay
    Supply Ability : 1 Million pieces per Month
    Delivery Time : Immediate
    • Product Details
    • Company Profile

    Electronic Components 4-Channel Single ADC SAR 500ksps 16-bit Parallel/Serial 48-Pin LQFP AD7654ASTZ Integrated Circuits

    Electronic Components 4-Channel Single ADC SAR 500ksps 16-bit Parallel/Serial 48-Pin LQFP Tray AD7654ASTZ Integrated Circuits



    Technical Specifications :


    Package Length7
    Package Width7
    Package Height1.4
    PCB changed48
    MountingSurface Mount
    Lead ShapeGull-wing
    Converter TypeGeneral Purpose
    ArchitectureSAR
    Resolution16bit
    Number of ADCs1
    Number of Input Channels4
    Sampling Rate500ksps
    Digital Interface TypeSerial (2-Wire, SPI, QSPI, Microwire)|Parallel
    Input TypeVoltage
    Input Signal TypeSingle-Ended
    Voltage ReferenceExternal
    Polarity of Input VoltageUnipolar
    Voltage Supply SourceAnalog and Digital
    Input Voltage5V
    Minimum Single Supply Voltage (V)4.75
    Typical Single Supply Voltage (V)5
    Maximum Single Supply Voltage (V)5.25
    Typical Power Dissipation (mW)120
    Maximum Power Dissipation (mW)135
    Integral Nonlinearity Error±3.5LSB
    Full Scale Error±0.5%FSR
    Signal to Noise Ratio90dB(Typ)
    No Missing Codes (bit)16
    Sample and HoldYes
    Single-Ended InputYes
    Digital Supply SupportYes
    Minimum Operating Temperature (°C)-40
    Maximum Operating Temperature (°C)85
    PackagingTray
    Pin Count48
    Supplier PackageLQFP
    Standard Package NameQFP


    for product datasheet, CONTACT US directly.
