1520 Kg Vibration Electric Starch Sifter Sweet Potato Starch Making
Machine
1. Description of starch sifter
Zhengzhou Jinghua starch sifter is widely used in starch industry
and it is proved the best sifter in starch sifting. The sieve body
is composed of many layer sieve lattices and the sieve cases have
two kinds of material: wooden and aluminum alloy. Each layer
connects closely as the form of step in the rim to ensure good
sealing performance and convenient maintainance. Suspender is made
from glass fiber reinforced plastic with durable life.
Advantages of starch sifter
1. Enclosed mild steel box cabinet for greater flexibility of flow
due to additional outer (4) channels.
2. Simple design allows easy maintenance.
3. Alum (Aluminium) style sieve inner frames, mesh cloth glued with
frame fast and activator.
4. Outer sieves coated inside and outside with plastic melamine
lamination and supplied with stainless steel trays.
5. Plan sifter doors made of fiberglass with a bright and smooth
finish, with insulation to prevent condensation.
6. Supplied with outlets for discharge, including inlet and outlet
socks and black plastic caps.
7. Easy and quick changing of sifting scheme if necessary.
Working principle
The machine is composed of two main parts: the mild steel frame
mounted with clamps for the flexible suspension rods, floor plates
for mounting and the mild steel box section for the sieve frames
with upper clamping by means of a metal frame and clamping pressure
micrometric screws.
The drive unit with counter balance weight, with motor, pulleys,
v-belt is mounted under the cabinet box section, adjustable to suit
different applications. Material is fed into the top and by the
machines circular motion, the fine material moves through the sieve
mesh and is discharged out each sieve side to outlets, while the
course material over tails and sent to separate outlets.
Main technical parameters
| Model | Bin (Piece) | Number of sieves (piece) | Capacity (t/h) | Diameter (mm) | Power (Kw) | Weight (kg) | Dimension (mm) |
| GDSF2x10x100 | 2 | 10-12 | 8-10 | Φ45-55 | 2.2 | 1200-1500 | 2530x1717x2270 |
| GDSF2x10x83 | 2 | 8-12 | 5-7 | Φ45-55 | 1.5 | 730-815 | 2120x1440x2120 |
| GDSF1x10x83 | 4.5 | 2-3 | 3-4 | Φ40 | 0.75 | 600 | 1380x1280x1910 |
| GDSF1x10x100 | 6.4 | 3-4 | 4-5 | Φ40 | 1.5 | 750 | 1620x1620x1995 |
| GDSF1x10x120 | 7.6 | 4-5 | 5-6 | Φ40 | 1.5 | 950 | 1890x1890x2400 |
2. Packing & Shipping
Packing & Shipping: Customize the wooden case according to the size
of the product.
Delivery: 14 days after receiving pre-payment (on time according to
contract strictly).
