Introduction and function
This machine applies the transmission principle. It uses the slot
wheel dividing system to drive the turntable to do intermittent
movement. The machine has 8 sits. Expect manually putting the tubes
on the machine, it can automatically fill the material into the
tubes, heat both inside and outside of the tubes, seal the tubes,
press the codes, and cut the tails and exit the finished tubes.
Filling measurement is accurate. Heating time is stable and
adjustable. Sealed tail looks pretty and neat and the trimming is
very even. This machine has stable performance and work without any
noise and pollution.
The part which is contact with the filling material is made of
high-quality stainless steels. The parts which need to clean are
made of quick-change device that is removable and convenient for
washing.
If some materials need heating insulation, the heating thermostat
device can be added outside of the feeding barrel.
Main functions:
1. automatic tube orientation
2. automatic heating
3. automatic sealing and pressing the batch, dates
4. automatic cutting the tail
5. automatic exiting
Application range:
It can fill and seal the plastic tubes and plastic-aluminum
laminated tubes. It is widely used in the cosmetic, medicine,
adhesive and shoe polish, food industries.
Main Features
1) Automatic tube loader-Automatic print registration-Tube
orientation checking-Fiiling-Inner Heating-Sealing and Dater
Printing-Cutting-Discharge
2) Adopting advanced world famous brand Mitshubish, Schneider,
Omron, Leister erccomponents in pneumatic parts ,electric parts and
operation parts.
3) High Standard quality control and safety protection.
4) Mechanical transmission device provide stable and easy
operation.
5) Could match cartoning machine and film packing machine together.
