Spectroscopy Medical Diagnostics 2000 μM Polyimide Silicon Fiber

Silicon Fiber from 25 μm Core Diameter to 2000 μm

Silicon Fiber from 25 μm Core Diameter to 2000 μm for Spectroscopy, Medical diagnostics

Technicaldata

Wavelength / spectralrangeUV:190 – 1200nm

WF:300 – 2400nm

Numerical aperture(NA)0,12 ± 0,02|0,22 ± 0,02|0,28 ± 0,02orcustomised

Operating temperature-190bis+350°C

Core diameter Available from 25 to 2000μm

Standard core / cladding ratios1 : 1,04|1 : 1,06|1 : 1,1|1 : 1,15|1 : 1,2|1 : 1,25|1 : 1,4 or customised

OH content UV:high(>700ppm)

WF:low(<1ppm)

Fibers with OH contents<0,25ppm are available upon request

Standard proof test100kpsi (nylon,ETFE,acrylate jacket) |70kpsi (polyimide jacket)

Minimum bending radius50 × cladding diameter(short-term mechanical stress)

150 × corediameter(during use with high laser power)

◆ Fine transmission performance at ultraviolet waveband, antiγ-ray at 800nm;

◆ Applied in ultraviolet spectrum analysis, laser transmission, health detection, nuclear energy and

semiconductor etc;

◆ NA=0.22±0.02 (0.1to 0.28 on request);

CCDR: 1:1.04, 1:1.1, 1:1.2 (1:1.06, 1:1.15, 1:1.25, 1:1.4on request)

First choice for applications including spectroscopy, medical diagnostics, medical technology, laser delivery systems and many more.
