    Cement Vertical Mill And Limestone Vertical Mill Factry With Capacity 500-5000tpd

    Ask Lasest Price
    Brand Name : ZTIC
    Certification : ISO
    Supply Ability : 10.0 Set/Sets per Month
    Price : negotiable
    Model Number : i
    Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
    • Product Details
    • Company Profile

    Cement Vertical Mill And Limestone Vertical Mill Factry With Capacity 500-5000tpd

    Products Description
    Vertical Mill
    • Cement Vertical Mill
    • Coal Vertical Mill
    • Raw Vertical Mill
    • Slag Vertical Mill

    We holds the leading position among all building materials equipment suppliers in China, and is the national export base for complete equipment supply.
    We can supply complete machinery requirements for 6000-10000 t/d production lines and can accept turnkey projects for 5000 t/d cement plants. We have cooperated with, and exchange technologies with, world leading companies such as F.L.Smith in Denmark, Leosche in Germany and others. We have a good reputation in making large Rotary Kilns, large Ball Mills and large Roller Presses used in the Building Material Equipment Industry.
    We also have registered “Chinese Brand” names for our key equipment.
    Our market share in this industry is over 65%.
    Vertical Mills
    2001 - Mass Production of large ATXO equipment for FLSmidth in Denmark
    2005 - In cooperation with LOESCHE produced the largest vertical mill in Asia
    2005 - Cement Slag Mill - Model LGMS4624 (Jiangsu Leida Co.)
    2006 - In cooperation with FLSmidth produced a large OK Vertical Mill
    As a professional manufacturer and supplier of vertical mill in China, we can also provide you with various other
    machines, such as vertical coal mill, jaw crusher, cement production line, cement grinding plant, industrial kiln and furnace, grinding equipment, crushing equipment, environmental protection equipment, cooling equipment, drying equipment, compound fertilizer equipment, packing machine, chemical equipment and electrical control system. Most of our products have passed the certification of ISO9000 and CE, and they have been quite popular among customers from as many as 60 countries and districts such as Germany, Russia, Brazil, Egypt, Iran, Japan, South Korea, Bengal, Pakistan, Turkey, Burma, Vietnam, South Africa, Columbia, Bolivia, etc. If you need vertical slag mill, please don't hesitate to contact us.

    Cement Vertical Mill

    * Application Industry
    Cement Plant, Grinding Station
    * Output
    55~250 t/h
    * Specific Surface
    3300~3800 cm²/g
    * Power Consumption of System
    25~30 kWh/t
    Features
    1. Technique and technology is mature and stable
    CITICIC’s cement vertical roller mill in the production of cement specific surface area up to 3800 cm²/ g with stable and
    reliable quality, it already have been the ability completely to replace tube mill.
    2. Reducing the power consumption of cement clinker preparation effectively
    According to the display of pulverized coal measured data, it can be saving electricity above 30% use of vertical roller mill production per ton cement clinker than traditional tube mill, and the power saving effect is very remarkable.
    3. Stable, high-efficiency and environmental protection
    There is a low vibration and noise in overall system, and equipment with whole sealing, system working under negative pressure with no dust overflow, clean environment. Therefore, cement vertical roller mill meets the national environmental protection requirements. With working mechanism changing, cement vertical roller mill can be reduced friction and improved service life.
    4. With a strong casting capability and short delivery period
    Great wall is the third enterprise which has a large-scale complete set casting company in domestic, and it can meet casting capability of single 120t, meanwhile, it has a large-scale machining workshop, can reduce the delivery period of cement vertical roller mill greatly.

    Raw Material Vertical Mill

    * Application Industry
    Cement Plant
    * Output
    70~720 t/h
    * Final Product Fineness
    80 μmR 12~15%
    * Power Consumption of System
    17~20 kWh/t
    Features of Raw Vertical Mill:
    Our vertical raw mill has various advantages when compared with other similar machines. Detailed information will be given in the following.
    1. High grinding efficiency: advanced grinding principles makes it possible to save as much as 20~30% power consumption when compared with the ball mill. With the increasing of moisture content, it can save more and more electricity.
    2. Strong drying capacity: it can make use of the hot waste gases from the kiln to do drying, and it is capable of drying and
    grinding raw materials with moisture content as much as 15%.
    3. Small in size, and simple process flow: it has integrated crushing, drying, grinding, separating and conveying into one body.
    4. Low noises and little dust: there is no direct contact between the grinding rollers and grinding disc. So metallic impact is avoided and its noises is 20~25 decibels lower when compared with ball mill. Totally closed negative pressure operation has employed by this vertical raw mill, so there is no dust during the operation, which can help to keep the production environment clean.
    5. Low wear rate and little metallic pollution: its metal wear is only 5~10g/t.
    6. With stable chemical composition and even particle size, its products are quite easy to calcine.

    Coal Vertical Mill

    * Application Industry
    Cement Plant, Steel Mill, Power Plant
    * Output
    5~70 t/h
    * Final Product Fineness
    80 μmR 3%
    * Power Consumption of System
    18~22 kWh/t
    Description of Coal Vertical Mill:
    This vertical coal mill is typically designed to process materials in medium hardness, like soft coal or bituminous coal, and it
    is mainly used in positive pressure pulverizing system of soft coal. It is widely used in electricity field, metallurgy sector,
    building material industry, chemical industry, and so on.
    It has features of low energy consumption, small occupation area, easy operation, low noises, reliable performance, big crushing
    ratio, long-lifespan grinding components, strong applicability, and so on.

    Slag Vertical Mill

    * Application Industry
    Cement Plant, Grinding Station, Steel Mill
    * Output
    50~180 t/h
    * Specific Surface
    4200~4500 cm²/g
    * Power Consumption of System
    ≤43 kWh/t
    Description of Vertical Slag Mill:
    Our vertical slag mill is typically designed to deal with industrial waste residues generated by the blast-furnace ironmaking. Due to its high physical and chemical activity, and potential hydraulicity, the slag has been widely as admixture matters in the cement industry. And the slag can replace the cement in the concrete to improve the quality and durability of the concrete.
    Our vertical slag mill has features of high grinding efficiency, strong dry capacity, easy adjustment, low noises, low electricity consumption, simple process flow, little abrasion, and so on.
    FAQ
    Q: Why we believe in luoyang zhongtai industries co., ltd: A: 1. More than 30 years experience. 2.We are the leading professional supplier of mining machinery, construction machinery, machines casting and forged parts. 3. All products achieved ISO9901:2000 quality management certificate and CE, ROHS certificates. Q:Delivery time A: parts lead time 1-2months, machines 2-3months. Q:Payment terms A: Accept payment type: T/T, L/C, Western union,Cash. 30% deposit when signed contract. Full payment paid before shipping Q: Quality warranty? A: guarantee time: one year for main machinery. If something wrong we will provide the technical advice and find solution immediately. For those wearing parts we guarantee high quality parts for long-term supply. Q: After sales service? A: we can supply technical guide for machines running test and parts maintenance if end user needs.
