Mirror Surface Planet Motion Planetary Mixer Machine /
Pharmaceutical Powder Mixer
Description
The mixing barrel moves in multi-directions. Materials have no
centrifugal force effect, specific gravity segregation, lamination
and accumulation during mixing. Mixing rate can reach over 99%. So
far, this machine is one ideal mixer among all kinds of mixers. The
loading capacity of barrel is good. it can reach 80%(40&%for
normal ones).
Each part of drum is transited by circle arc and polished
precisely, meeting the GMP requirements.This machine is used high
homogeneity mixing of powdery and particle materials in such trades
as pharmaceutical, food, chemical, light industry, machinery,
electronics, mining and metallurgy, national defense industry and
scientific research etc.
Application
pharmaceutical use mirror surface planet motion powder blender is widely applied in pharmaceutical, chemical, foodstuff, battery,
plastics, metallurgy industries and research industries for
homogeneous mixing.
Features
1) Simple structure in linear type ,easy in installation and
maintation.
2) Adopting advanced world famous brand components in pneumatic
parts ,electric parts and operation parts.
3) High pressure double crank to control the die opening and
closing.
4) Running in a high automatization and intellectualization,no
pollution
5) Apply a linker to connect with the air conveyor ,which can
directly inline with filling machine .
Working Principple
The barrel for charging the materials is driven by the driving
shaft. The barrel body carries on the repeated level movement,
rotation, turning and other complex movements so that the materials
will carry out the three dimensions and complex movements along the
barrel body so as to realize the various movements of the
materials. Through disseminating, gathering, agglomerating and
mixing to realize uniform mixing.
Technical Parameters
| Model Item | SYH-15 | SYH-50 | SYH-100 | SYH-200 | SYH-400 | SYH-600 | SYH-800 | SYH- 1000 | SYH- 1200 | SYH- 1500 |
| Barrel capacity/L | 15 | 50 | 100 | 200 | 400 | 600 | 800 | 1000 | 1200 | 1500 |
| Max loading capacity/L | 12 | 40 | 80 | 160 | 320 | 480 | 640 | 800 | 960 | 1200 |
| Max loading weight/KG | 6 | 20 | 40 | 80 | 160 | 240 | 320 | 400 | 480 | 600 |
| Speed of driving shaft/ R/min | 0~28 | 0~8 |
| Motor power/kW | 0.37 | 1.1 | 1.5 | 2.2 | 4 | 5.5 | 7.5 | 7.5 | 11 | 11 |
| Overall dimension/mm | L | 750 | 1400 | 1700 | 1800 | 2100 | 2400 | 2600 | 2650 | 2950 | 3100 |
| W | 1000 | 1000 | 1200 | 1400 | 1800 | 2200 | 2380 | 2500 | 2650 | 2850 |
| H | 700 | 1200 | 1500 | 1600 | 1950 | 2350 | 2500 | 2600 | 2750 | 3000 |
| Total weight/Kg | 200 | 300 | 500 | 800 | 1200 | 1500 | 2000 | 2500 | 3000 | 3500 |
