300 model auto feeding Fluidized bed Dryer for foodstuff drying
Scope of application
1. Use screw to extrude and vibrate granule and granulate the
granule with the method of humidity, high speed and mixing
2. Suitable for drying humidity block or powder raw material in the
fields such as pharmaceutical, foodstuff, feed stuff, chemical
industries and so on
3. The raw material that large in granule and small in block and
having adhesive property
4. Suitable for raw materials, its volume will be changed when dry,
such as giantarum, polyacrylamide, etc.
Principle
When air is purified and heated, it is introduced from the bottom
of induced-draft fan and passed through the screen plate of raw
material. In working chamber, the state of fluidization is formed
through stirring and negative effect. The moisture is evaporated
and removed rapidly and the raw material is dried quickly.
Features
1, The structure of fluidization bed is round so as to avoid the
dead angle
2, Inside the hopper there is a stirrer in order to avoid
agglomeration of raw material and forming canal of flow
3, The granule is discharged through the method of turning over. In
this way it is very convenient. The discharging system can be
designed as required too
4, It is operated at the condition of negative pressure and seal.
The air is filtered. Therefore it is simple in operation and
convenient in clean. It is an ideal equipment that is in conformity
with the requirements of GMP.
5, The drying speed is fast and the temperature is uniform. In
general, the drying time is 15-45 minutes each batch
Technical Parameters
| Item | unit | Model |
| 3 | 5 | 30 | 60 | 120 | 200 | 300 | 500 |
| container | volume | liter | 12 | 22 | 100 | 220 | 420 | 670 | 1000 | 1500 |
| diameter | mm | 300 | 400 | 700 | 1000 | 1200 | 1400 | 1600 | 1800 |
| capability | min | kg/batch | 1.5 | 4 | 15 | 30 | 80 | 100 | 150 | 250 |
| max | Kg/batch | 4.5 | 6 | 45 | 90 | 160 | 300 | 450 | 750 |
| fan power | kw | 3 | 4 | 7.5 | 11 | 18.5 | 22 | 30 | 45 |
| steam consumption | kg/h | 15 | 23 | 70 | 141 | 211 | 282 | 366 | 451 |
| Compressed-air consumption | m3/min | 0.3 | 0.3 | 0.3 | 0.6 | 0.6 | 0.9 | 1.1 | 1.6 |
| temperature | ℃ | adjustable at the range from room temperature to 120℃ |
| working time | min | decided in accordance with the properties of raw materials |
| collect rate | % | ≥99 |
| noise | dB(A) | <75 |
| Height of main machine | mm | 2100 | 2300 | 2500 | 3000 | 3300 | 3800 | 4000 | 4400 |
All data for reference only. According to the material features, we
have the right to change but not notice, pardon!
