1.Product introduction
The equipment has high accuracy, the temperature measurement error
is less than 0.2 ℃, and the single temperature testing speed is
less than 0.5 second. It is very suitable for rapid temperature
measurement for crowded areas or places without security or medical
staff to hold the temperature gun. Effectively improve the
temperature measurement efficiency, increase the passage rate,
reduce the number of medical personnel, reduce personnel cost,
etc., compare with the temperature testing gun has a wider
applicability and application advantages.
The intergrated device can be used as a stand-alone device, or as a
supporting device for face recognition access control, access gate,
security door, etc. The device use DC12V power supply, which can be
easily to mesurement.
2.Product function features
Distance sensor:Laser distance sensor, accurate judge the distance
of palm, raise detection accuracy and efficiency.
Temperature sensor:High accurate temperature sensor, Combined with
distance data for cross analysis, the proprietary temperature
measurement algorithm, through Palm temperature accurate conversion
of human body temperature.
The equipment adopts double rotating brackets, supports multi-angle
adjustment, and the installation method can be wall-mounted, placed
on the table, or fixed to the channel gate and security gate, which
is convenient and flexible, and is suitable for various scenarios.
3.Specification
| 项目 Item | 说明 Note |
测温方式 Testing way | 单点式测温 Single-point temperature measurement |
距离探测 Distance detection | 激光 Laser |
测温速率 Testing speed | 0.5-0.8 second |
最大检测视角 Max testing view angle | 5° |
温度测量辨析度 Temperature measurement resolution | 0.1℃ |
准确度 Accuracy | ±0.2℃ |
测温距离 Testing distance | 2-8cm |
蜂鸣器 Buzzer | 内置蜂鸣器 Built in buzzer |
可测量温度范围 Available temperature range | 30.0℃~99.9℃ |
设备最佳工作环境温度 Device best working environment temperature | 15℃~40℃ |
供电电压 Supply Voltage | DC12V |
工作电流 Working current | 0.2A |
电源适配器 Power adpator | 配1台AC220V转DC12V电源适配器 With 1 pcs AV220V convert DV12V power adaptor |
设备尺寸 Device Size | 246*166*50mm |
外包装尺寸(单台) Package Size | 339*207*94mm |
重量(单台) Weight(pcs) | ?kg |
