Easy operating
Intelligent guide design,
even if you are green hand, you can also finish checking quickly.
Perfect imaging
ASG detector
Highly configuration liquid metal tube
Non-destructive optical path
Humanization design anywhere
Pay attention to the details design
Create a microradiation scanning experience
Prostar 6KVA UPS Used For CT Machine At Hospital
INQUIRY DETAILS *
6000 Series Low Frequency Online UPS has been designed as
combined advanced IGBT technology with hi-frequency wider-modulated
technology (PWM), which make customer could obtain hi-quality power
output and optimized efficiency under each operation load. And the
advanced modular design to reduce the average time to repair
(MTTR), and the best maintenance.It also with the most advanced
phase-balanced technology, and it features best stability, even if
loss-phase, it could still operate at normal condition, so it’s
suitable for any worse power supply.Double conversion, pure sine
wave output line design could supply the low-distortion pure sine
wave power, so it can provide the best power protection to the
users’ equipment And with the isolated output transformer, which
ensure that the entire the isolation of the load and public
electric.
6KVA UPS is three phases in & Singlephases out ups.Due to its
prominent industrial and electronic design, the UPS not only could
work safe in the harsh environment, but also could provide maximum
protection office automation, network, security applications and
industrial applications.
Main Features1. Intelligent control of multiple CPUGroups of new
microprocessor (CPU) co-ordination,which can precisely control the
parameters of UPS and its full control,providing sufficient
computing power, to ensure UPS always in top working condition.
2. Humanized display interfaceLCD dot matrix display,which
visually indicated the UPS’s operating parameters.LED displays the
working status of UPS,and the LCD + LED combinations could make you
get the UPS running status clearly and quickly.
3. High-intelligence network controlThrough the communication
interface,with the monitoring software,which can directly monitor
UPS on the computer,simplified power management;optional adapter
remote monitor (SNMP card),with a variety of operating system and
application software,as well as TCP / IP , SNMP,HTTP and other
protocol support,which meets the users′requirements to monitor UPS
via network, this is more suitable for decentralized users to
centralized manage,thereby achieving the real global Management.
4. Not principal and subordinate type, but adaptive parallel
technologyIt has strong ability in parallel and does not need to
set the quantity of parallel, it can be arbitrary online parallel
expansion or N + 1 redundancy in parallel. Parallel UPS will share
the same group batteries.
5. Intelligent battery managementAdopts a three-stage charging
method, which is good for recovery for the deep discharge of the
battery.Independent current sharing and parallel charger, which can
increase he capacity according to request.It can guarantee the
charging request for the long backup UPS system.With the battery
reverse connect protection, short circuit protection and over
temperature protection, and other functions.
| SU6K(Single in and Single out) |
| Model | SU6K |
| Capacity (VA/W) | 6K/4.8K |
| Input Voltage | Single phase with two lines+ground wire ,220V±25% |
| Battery Voltage | 192V |
| Built-in Battery | NO |
| Noise | ≤55dB(Distance |
