    Pulverized Coal Chain Scraper Conveyor Double Chain Mining Scraper

    Ask Lasest Price
    Brand Name : PK
    Model Number : MS160/200/250/320/400/500mm
    Certification : CE Certificate,ISO9001:2008, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 600SETS/YEAR
    Delivery Time : ABOUT 30 DAYS
    • Product Details
    • Company Profile

    Pulverized Coal Chain Scraper Conveyor Double Chain Mining Scraper

    Pulverized Coal Chain Scraper Conveyor Double Chain Mining Scraper


    Introduction

    Pulverized coal chain scraper conveyor double chain mining scraper is a new product for horizontal (or inclined 15%) conveying powdery, granular and small block materials.This product design is reasonable, the structure is novel, the service life is long, its service performance obviously surpasses the spiral conveyor, the buried scraper conveyor and other conveyor equipment, is one kind of ideal new conveyor equipment.The products are widely used in building materials, chemical industry, mining, metallurgy, electric power, grain and oil processing, machinery, transportation, port and transportation industries


    Pulverized coal chain scraper conveyor double chain mining scraper is a conveying equipment which is traction components on the roller chain plate and continuous. This type of device with compact structure, good sealing, rational layout, application convenient maintenance, etc.

    It is mainly used for grinding powder, particle, small lump with strong abrasive in horizontal or inclination, also widely used in chemical industry, metallurgy, mining, building materials, electric power, light industry, traffic, road construction, food processing industry, port, etc.




    Advantages and Features


    1. Totally enclosed structure, without pollution, environmental friendly.
    2. Simple structure, convenient installation and maintenance.
    3. Horizontal or slightly inclined transport, angle can be from 0° to 30°.
    4. Multiple material feeding point and discharging point according to requirement.
    5. Trough width can be 160-500mm to meet different material types and capacity.
    6. Kinds of scraper chain, to meet different types of material.
    7. Conveying distance is up to 80m with material temperature lower than 120℃.
    8. With screw take-up device, can take-up itself automatically, to avoid chain take off.
    9. Reducer motor brand can be can be domestic or imported: Tailong,,Siemens etc.
    10. Can be disassemble into several sections, save space during transportation.


    Technical Parameter:


    Scraper Conveyor Technical Performance
    TypeMS16MS20MS25MS32MS40
    Trough Width160200250320400
    Allowed Material Density Range0.2-2.5t/m³
    Max.Conveying Distance120m
    Conveying Capacityspeed m/s0.160.160.160.160.16
    capacity m³/h1523365983
    speed m/s0.20.20.20.20.2
    capacity m³/h18294574104
    speed m/s0.250.250.250.250.25
    capacity m³/h23365692130
    speed m/s0.320.320.320.320.32
    capacity m³/h294672118166


    Selection Conditions

    ♦ Material to be processed:

    _

    ♦ Installation angle:

    ___° (if the installation is inclined)

    ♦ Bulk density:

    t/m3

    ♦ lifting height:

    ___m (if there is slope angle)

    ♦ Water content:

    %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature:

    °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material:

    mm

    ♦ Working environment:

    (indoor or outdoor)

    ♦ Max. Granule size:

    mm

    ♦ Working environment temperature:

    °C

    ♦ Handling capacity:

    t/h

    ♦ Working power supply:

    3 Phase V Hz

    ♦ Conveying length (distance between inlet and outlet): m

    ♦ Quantity:

    sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
