Solid Or Stranded Copper Wire Interbus Cable With Pet Tape Wrapping Purple Jacket

Add to Cart

Solid Or Stranded Copper Wire Interbus Cable With Pet Tape Wrapping Purple Jacket

INTERBUS Cable



▉ Application
Cable widely used in many industrial field bus system, such as automobile,tobacco,warehouse,papermaking,food&beverage.
▉ Cable Construction
Conductor: Stranded bare copper wire
Insulation: PE
Shield: BC braid
Jacket: see attached list
Color: Green or purple

▉ Cable Construction
Oil and grease resistance
Torsion resistance,Easy bending
High braiding coverage,excellent Anti-EMI performance
UV and Abrasion resistance,Anti-hydrolysis

▉ Cross Section

▉ Technical data
Temperature range		.-40℃ to 80℃
Test voltage		1500V 1min,no breakdown
Characteristic impedance		110±15 Ohm
Min bending radius		10x cable diameter
Loop conductor DC resistance at 20℃		3P≤159.8 ohm/km 3C≤44 ohm/km

▉ Product List
Item No.	Spec.	Jacket	Nominal OD(mm)	Copper.weight approx (kg/km)	Weight approx(kg/km)
7131100	320.25mm²	PVC	7.5	32.5	63.5
7131101	320.25mm²	PUR	7.5	32.5	61
7131102	320.25mm²+3*1mm²	PVC	8.3	64	94
7131103	320.25mm²+3*1mm²	PUR	8.3	64	98

▉ Order Informations
Marking		HELLOSIGNAL Industrial INTERBUS Cable XXXFT/M
Package		100m/Reel, 300m/Wooden Spool
Delivery time		Normally 25 days after received the deposit.
