Soundproof Acoustic Folding Movable Partition Fabric Sliding Doors
Product description:
The partition panel is made of aluminum frame, special made rubber,
excellent sound insulation cotton, finish board, etc. The finish
panel is flat and hard; The finish panel is inserted in the
aluminum track, assembled with multi-direction wheels. The panel
can be stored in many different ways. BUNGE movable partition wall
is flexible and can be moved freely. And it has sound insulation,
heat insulation and fireproof function.
| Series | BG65 | BG85 | BG100 |
| Panel suspension | Top hung only |
| Panel thickness | 65mm | 85mm | 100mm |
| Max height | 4000mm | 6000mm | 8000mm |
| Panel width | 600-1230mm |
| Face material | 9mm | 9mm | 12mm |
| Sound insulation | 20-32db RW | 30-38db RW | 35-45db RW |
| Weight | 20-30 kg/sq M | 22-35kg/sq M | 28-40kg/sq M |
| Track system | Single or two point |
| Frame construction | Aluminum frame |
| Finish materials | Plywood, MDF, Laminate, Melamine, Gypsum board, Fabric, Leather,
Insulation board, Fireproof board, Wall paper, Vinyl, Painting,
etc. (Customized) |
Hanging system description:
The track and roller are fitted with magnetic membrances which
ensure positive interlocking of the panels. Once the wall panels
have been adjusted for height and level, the roller stems are
locked with a fail-safe mechanism to ensure that the panels will
align perfectly every time the wall is set up. Pressure seals
extend from the top and bottom of each panel exerting a closing
pressure of 2kg provicling pravicling panel stability and excellent
acoustic sealing.
Panel faces are suspended from a steel frame with just 1 or 2points
of contact. The edges of panel faces are slotted into aluminum
profiles. This method of cladding the steel frame allows the panel
faces to be acoustically separated from each other and thereby
minimises the transfer of sound waves through the system. Each
panel has an extruded aluminum male profile to one vertical edge
and a female profile to the other.
Advantages of sliding partition:
1. Individual panels that can be stored away for maximum space
utilisation.
2. Operable top and bottom seals for effortless operation.
3. Isolated aluminum frame construction for enhanced acoustic.
4. No floor track ensures free obstruction threshold.
5. Three panel sizes to accommodate a wide range of acoustic
requirements.
6. Extensive range of surface finshes can be qpplied.
Pass door:
A door in the partition can help you to go through freely. You can
choose to open a door or not according to your need. We use strong
force spring press device to fix the pass door (door-in-door)
instead of fixing method with ground spike that can destroy the
land.
FAQ
1.Q: Are you a manufacturer or trading company?
A: We are a famanufacturer, and this is our address: No.39-2,
Nanwei Road, Hailong street, Longxi Avenue, Liwan District,
Guangdong Province, China.
2. Q: What is the price of the movable wall?
A: Our mobile wall system is customized, the cost is calculated by
area, the thickness of different walls and the price of different finishes are different. Therefore,
we need you to provide us detailed dimensions such as height, width and finish requirements. If
possible, we also need your layout drawings.
3. Q: Is the movable partition acoustic (soundproof)?
A: Yes, our movable wall system is soundproof. We have different
acoustic material fillings and various sound absorbing panels to achieve different acoustic
ratings. For the 65 series we can reach 45db, for the 80 type we can reach 48db, the 85 type can
reach 50db, for the 100 type we can reach 50db.
4.Q: How to install an active partition? Is it difficult to
complete?
A: It is not difficult to install our active partitions. Our active
partition is a hanging rail type moving wall that does not require any ground track. Therefore the hanging rail
structure will be very important. We have very detailed drawings and videos showing how to install, so
your employees just need to follow them step by step.
5.Q: Do you provide sample?
A: Yes, and the sample is free, you just pay the express delivery
fee is ok.
6.Q: What is your payment terms?
A : 30% - 50% of total amount by T/T as deposit when confirmed the
order and balance paid by T/T before loading container, or irrevocable L/C at sight.
7. Q : What is your warranty ? What do we do in case of problems?
A : 3 years quality warranty is provided, including frame unfading
nor peel-off, hardware and accessories working properly under correct operation.In case of our
quality problem, we will provide replacement by international courier. Immediate delivery of
replacement parts with available in stock, and if not stocking, the time should be depending on material
ordering time which is normally 10- 15 days.
Very velcome to visit our Web and contact us!
Send us a question below to get a movable wall catolog and special
discounts!
