    BA Cold / Hot Rolled Inconel 625 Round Bar Astm Standard

    Ask Lasest Price
    Brand Name : JIN LAI
    Model Number : High Alloy Stainless Steel
    Certification : ISO
    Price : negotiable based on the quantity
    Payment Terms : T/T, Western Union, L/C
    Supply Ability : 3000 tons per month
    Delivery Time : within 15 days
    • Product Details
    • Company Profile

    BA Cold / Hot Rolled Inconel 625 Round Bar Astm Standard


    Inconel 625 is a corrosion and oxidation resistant nickel alloy that is used both for its high strength and outstanding aqueous corrosion resistance. Its outstanding strength and toughness is due to the addition of niobium which acts with the molybdenum to stiffen the alloy’s matrix. Alloy 625 has excellent fatigue strength and stress-corrosion cracking resistance to chloride ions. This nickel alloy has excellent weldability and is frequently used to weld AL-6XN. This alloy resists a wide range of severely corrosive environments and is especially resistant to pitting and crevice corrosion. Some typical applications Inconel 625 is used in are chemical processing, aerospace and marine engineering, pollution-control equipment, and nuclear reactors.

    forms

    • Sheet
    • Plate
    • Bar
    • Pipe & Tube (welded & seamless)
    • Wire

    characteristics

    • High creep-rupture strength
    • Oxidation resistant to 1800° F
    • Seawater pitting and crevice corrosion resistant
    • Immune to chloride ion stress corrosion cracking
    • Non-magnetic

    Chemical Composition, %

    Cr

    Ni

    Mo

    Co + Nb

    Ta

    Al

    Ti

    C

    Fe

    Mn

    Si

    P

    S

    20.00-30.00Remainder8.0-10.01.0 max3.15-4.15.40 max.40 max.10 max5.0 max.50 max.50 max.015 max.015 max

    applications

    • Aircraft ducting systems
    • Aerospace
    • Jet engine exhaust systems
    • Engine thrust-reverser systems
    • Specialized seawater equipment
    • Chemical process equipment

    Fabrication with Inconel 625

    Alloy 625 has excellent forming and welding characteristics. It may be forged or hot worked providing temperature is maintained in the range of about 1800-2150° F. Ideally, to control grain size, finish hot working operations should be performed at the lower end of the temperature range. Because of its good ductility, alloy 625 is also readily formed by cold working. However, the alloy does work-harden rapidly so intermediate annealing treatments may be needed for complex component forming operations. In order to restore the best balance of properties, all hot or cold worked parts should be annealed and rapidly cooled. This nickel alloy can be welded by both manual and automatic welding methods, including gas tungsten arc, gas metal arc, electron beam and resistance welding. It exhibits good restraint welding characteristics.

    ASTM Specifications

    Pipe Smls

    Pipe Welded

    Tube Smls

    Tube Welded

    Sheet/Plate

    Bar

    Forging

    Fitting

    Wire

    B444B705B444B704B443B446---

    Mechanical Properties

    Representative Tensile Properties, bar, 1800° F anneal

    Temp° F

    Tensile (psi)

    .2% Yield (psi)

    Elongation in 2 “ (%)

    70144,00084,00044
    400134,00066,00045
    600132,00063,00042.5
    800131,50061,00045
    1000130,00060,50048
    1200119,00060,00034
    140078,00058,50059
    160040,00039,000117
