Features of Granulator Machine
1. Gear directly-connecting driving is adopted for high efficiency;
2. Full stainless steel feeder; variable pitch anti-bridging
structure; Imported FC control;
3. Full stainless steel conditioner with axial steam spraying
extends the conditioning and cooking time;
4. Main gear and pinion shaft adopt the carbonizing quenching with
high accuracy; smooth driving, low noise and long service life;
5. Gearbox and driving holes’ accuracy are guaranteed by
specialized casting supplier and CNC;
6. The bearing and oil seal in the main drive are imported, and a
specialized lubrication oil return system is available to ensure
reliable bearing lubrication;
7. 3pcs of quick disassembling type precisely-cast die clamps are
adopted to connect the die and quill flange, resulting in
convenient and quick disassembling of die;
8. Pellet chamber door and feed chute are fully made of stainless
steel with high anti-corrosion ability and long service life;
9. The connection between motor and gearbox adopts new type S-shape
spring coupling for more convenient disassembling and assembling
and more reliable use.
Main Technical Parameters of Feed Pellet Mill
Parameters Model | Output (t/h) | Main Power (kw) | Power Of Conditioner(kw) | Power Of Feeder (kw) | ID Of Die (mm) | Pellet Size (mm) |
| SZLH400b2 | 3-12 | 75/90 | 5.5×2 | 1.5 | Φ400 | Φ2-18 |
| SZLH420b2 | 3-14 | 90/110 | 5.5×2 | 1.5 | Φ420 | Φ2-18 |
