Blue Vertical Marine Vertical Baler Machine Safe Manual Operation
Applications:
Y82 series of vertical balers can press & pack loose materials like
cotton & wool yarns, pieces of cloth, sacks, wool tops, etc. The
bales have larger density and uniform size, suitable for
containerized transportation. Y82 series arealso applied to press
paper, cardboard (carton), plastic film & bottle,straw (hay), &
thin metal, etc.
Features:
1. A wide range of baling forces from 3 to 315 tons.
2. Hydraulic drive, top-mounted cylinder(s).
3. Imported seal for all the cylinders.
4. Mainly used for compressing and baling of the woven bags/cloth,
waste paper, scrap paper
convenient for transportation and storage.
Technical parameters:
Baler for wool balls |
|
|
|
|
No. | Model | Nominal Force | Chamber Size | Number of Balls/time | Power | Bale discharging method |
1 | Y82-25Q | 250KN/25t | 1100*740*1400 mm | 18/24 | 15KW | Manual discharging,
manually operated directional valve operation |
2 | Y82-35Q | 350KN/35t | 1100*740*1400 mm | 18/24 | 15KW |
3 | Y82-63Q | 630KN/63t | 1100*740*1400 mm | 18/24 | 15KW |
4 | Y82-120Q | 1200KN/120t | 1100*740*1400 mm | 24/36 | 18.5KW |
5 | Y82-160Q | 1600KN/160t | 1100*740*2200 mm | 24/36 | 22KW |
6 | Y82-200Q | 2000KN/200t | 1080*740*2200 mm | 36/48 | 30/37KW |
7 | Y82-315Q | 3150KN/315t | 1080*740*2500 mm | 36/48 | 45KW | PLC control |
8 | Y82-25B | 250KN/25t | 1000*600mm | 1000*530mm | 11KW | Manual discharging,
manually operated directional valve operation |
1000*750mm | 1000*600mm | 11KW |
9 | Y82-63B | 630KN/63t | 1600*1000mm | 1350*900mm | 15KW |
10 | Y82-120B | 1200KN/120t | 1600*1000mm | 1350*900mm | 18.5KW |
11 | Y82-250B | 2500KN/250t | 1360*960mm | 1360*960mm | 22KW |
