    Rhenium Tungsten Alloy Plate Sheet Wre3/25 Wre5/26 With High Melting Point

    Ask Lasest Price
    Brand Name : JINXING
    Model Number : Tungsten Rhenium Sheet
    Certification : ISO 9001
    Price : 30~200USD/kg
    Payment Terms : L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 10000kgs/M
    Delivery Time : 10~25 work days
    • Product Details
    • Company Profile

    Rhenium Tungsten Alloy Plate Sheet Wre3/25 Wre5/26 With High Melting Point

    Tungsten Rhenium Plate

    WRe3%, WRe5%, WRe25%, WRe26%


    • Description

    Tungsten Rhenium Plate

    Uses: Tungsten-rhenium alloy has good electrical properties, ductility and processability, and can be used for thermocouple temperature measurement in high temperature furnaces.

    Applicable conditions: due to the excellent high temperature strength and high temperature plasticity of W-Re alloy, various structural parts, heaters and special-shaped parts made of W-Re alloy are widely used in aerospace, atomic energy, ultra-high temperature alloy, semiconductor magnetron sputtering, high temperature heat field and other industrial fields.


    3%, 5%, 25% and 26% rhenium can be added to tungsten to form tungsten rhenium alloy. The wire material can be used for thermocouple wire and cathode wire of high temperature measurement. Adding 41% - 47.5% rhenium into molybdenum to form molybdenum rhenium alloy (nominal composition is 50% Mo + 50% RE). It has good high temperature ductility and is applied in electronic industry, nuclear industry and * * aerospace industry.


    Because rhenium has very excellent properties in the following table, adding rhenium into tungsten to form tungsten rhenium alloy, and adding rhenium into molybdenum to form molybdenum rhenium alloy, the electrical properties, high temperature ductility and processability of the alloy can be greatly improved and strengthened, which can be widely used in high temperature heating body, temperature thermocouple, cathode of electronic tube and other high temperature parts. We can make all kinds of tungsten rhenium / molybdenum rhenium alloy products according to customer's requirements, which can be in the form of wire, rod, sheet, plate or other special-shaped parts.


    Thermocouple TypeTemperature range℃Tolerance
    WRe3/250~4004.0℃
    400~2300±0.25%t
    WRe5/260~4004.0℃
    400~2300±0.5%t

    NameType:(mm)
    Tungsten Rhenium Thermocouple WireWRe3/25, WRe5/26φ0.1,φ0.2,φ0.25,φ0.3,φ0.35,φ0.5
    Tungsten Rhenium Alloy WireWRe3%, WRe5%, WRe25%, WRe26%φ0.1,φ0.2,φ0.25,φ0.3,φ0.35,φ0.5
    Tungsten Rhenium ThermocoupleWRe3/25, WRe5/26It is used in vacuum, hydrogen and inert atmosphere, and its service temperature range is 0 ~ 2300 ℃
    Tungsten Rhenium Alloy Rod/BarWRe3%, WRe5%, WRe25%, WRe26%φ1-φ35
    Tungsten Rhenium Alloy sheet/PlateWRe3%, WRe5%, WRe25%, WRe26%0.2min x (10-350) x600max.
    Tungsten Rhenium Alloy Round discWRe3%, WRe5%, WRe25%, WRe26%Customized
    Tungsten Rhenium Alloy tube/PipeWRe3%, WRe5%, WRe25%, WRe26%

    Rhenium is a rare metal element, located at the 75th position of the periodic table of elements, adjacent to tungsten (74). Rhenium is known for its melting point of 3180 ℃, which is the second refractory metal.


    In the field of alloy, tungsten and molybdenum are the most combined metal elements with rhenium. Rhenium can improve the strength and plasticity of tungsten and molybdenum at the same time, which is called "rhenium effect". Adding a small amount of 3% ~ 5% rhenium can increase the recrystallization starting temperature of tungsten by 300 ℃ ~ 500 ℃, and improve its high temperature strength and plasticity.


    Rhenium alloy has a series of excellent properties, such as high melting point, high strength, high hardness, high plasticity, high recrystallization temperature, high resistivity, low vapor pressure, low electron work and low plastic brittle transition temperature.
