    Flange Mounting Diaphragm Seal Pressure Gauge High Reliability Good Specification

    Ask Lasest Price
    Brand Name : ZHYQ
    Model Number : PT124Y-624
    Certification : CE,RoHS
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : 5000PCS / Week
    Delivery Time : 7-10 days
    • Product Details
    • Company Profile

    Flange Mounting Diaphragm Seal Pressure Gauge High Reliability Good Specification

    Flange mounting diaphragm pressure gauge high reliability and good specification PT124Y-624

    PT124Y-624 adopts high performance imported bourdon tube, designed with special shockproof configuration, flange mounting structure, high pressure endurance; Make it is suitable for the process pressure measuring in the machinery such as homogenizer, petroleum and chemistry equipment, fiber equipment, food machinery and so on.


    Application
    Petroleum and chemistry equipment
    Fiber equipment
    Medicine
    Food machinery


    Feature
    Special mechanical design
    To install easily
    Good shockproof and corrosion prevention
    High reliability and good specification


    Specification

    Range0….700bar to 0….1500bar
    Accuracy±1.6%FS
    ConfigurationBourdon tube
    Over Pressure1.5×FS
    Max Diaphragm Temperature150℃
    Dial Diameter100mm
    Process Connection

    Flange design


    Ordering Guide

    ModelRangeOutputProcess connectionOther requirement
    PT124Y-624---none------
    Example: PT124Y-624-700Bar-Flange
