    arc welding robot FD-V8 tig weld 6 axis welding robotic arm with air plasma cutting and material-handling applications

    Ask Lasest Price
    Brand Name : OTC
    Model Number : FD-V8
    Price : negatiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 50
    Delivery Time : 4-12 week
    • Product Details
    • Company Profile

    arc welding robot FD-V8 tig weld 6 axis welding robotic arm with air plasma cutting and material-handling applications

    robotic welding FD-B4S 7 axis robot arm and welding torches and tig welding machines for sale for OTC


    Product description


    SpecificationValue
    Number of Axes6
    Maximum Payload Capacity8 kg
    Positional Repeatability± 0.08 mm
    Drive Capacity3016 W
    Working Range, Arm, J1 (Rotation)± 170° (±50°)
    Working Range, Arm, J2 (Lower Arm)- 155° to + 90°
    Working Range, Arm, J3 (Upper Arm)- 170° to + 190°
    Working Range, Wrist, J4 (Swing)± 180°
    Working Range, Wrist, J5 (Bending)- 50° to + 230°
    Working Range, Wrist, J6 (Twist)± 360°
    Maximum Velocity, Arm, J1 (Rotation)4.19 rad/s (240°/s) (3.32 rad/s (190°/s)
    Maximum Velocity, Arm, J2 (Lower Arm)4.19 rad/s (240°/s)
    Maximum Velocity, Arm, J3 (Upper Arm)4.01 rad/s (230°/s)
    Maximum Velocity, Wrist, J4 (Swing)7.50 rad/s (430°/s)
    Maximum Velocity, Wrist, J5 (Bending)7.50 rad/s (430°/s)
    Maximum Velocity, Wrist, J6 (Twist)11.00 rad/s (630°/s)
    Wrist Load, Allowable Moment, J4 (Swing)17.6 N*m
    Wrist Load, Allowable Moment, J5 (Bending)17.6 N*m
    Wrist Load, Allowable Moment, J6 (Twist)7.8 N*m
    Wrist Load, Allowable Moment of Inertia, J4 (Swing)0.43 kg*m²
    Wrist Load, Allowable Moment of Inertia, J5 (Bending)0.43 kg*m²
    Wrist Load, Allowable Moment of Inertia, J6 (Twist)0.09 kg*m²
    Arm operation cross-sectional area3.11 m² x 340°
    Ambient Conditions0~45°C, 20 ~ 80% RH (No condensation)
    Mass140 kg
    Upper arm payload capacity10 kg
    Installation typeFloor / Ceiling / Wall
    Paint colorWhite (Munsell notation 10GY 9/1)
