    Fast Speed MS Pipe Making Machinery Fully Automation High Accuracy ERW Tube Mill

    Ask Lasest Price
    Brand Name : HOOHA
    Model Number : HH-114
    Certification : ISO CE
    Price : 70000-75000USD/set
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1 set/3 month
    Delivery Time : 80 working days
    • Product Details
    • Company Profile

    Fast Speed MS Pipe Making Machinery Fully Automation High Accuracy ERW Tube Mill


    114 Tube mill Line



    High‐frequency welded tube mill line is designed to produce round tube diameter of 25.4 – 114 mm, and wall thickness of 0.8 ‐4.0 mm. This line utilizes roll forming to process steel strip into various shapes.

    Using high frequency induction heating, this line is capable of producing section material of various diameters and sizes by squeezing weld seam together into closed shape.

    The application of advanced aperture technology, PLC automatic control system and British Eurasia Digital speed‐regulating unit ensure that the production line works reliably and operates and maintains easily.



    Specification
    Raw materialCarbon Steel, Cold or Hot Rolled pre slit strip coils of weld able grade with max. 0.2% carbon.
    Round tube O.D.Min 25.4mm, max.114.3mm
    Wall thickness of RoundMin.0.8mm, max.4.0mm
    Square tubeMin 20x20mm, max90x90 mm
    Rectangle tubeMin 20x30mm, max60x120 mm
    Wall thickness sq & rec.Min.0.8mm, max.3.5mm
    H.F. welderSolid state,300 kW
    Line SpeedMax 80 m/min
    Tube length5 – 12 m
    Tube length accuracy±2mm per 6m length


    Coil loading—Uncoiling‐Strip joining—accumulator—Forming,‐H.F. Welding–Bead Remover ‐Cooling—Sizing & straightening‐Measuring roll—Flying saw cutting—Run out conveyor
