Cataphoretic Coating QB Series Vortex Aquarium Pump For Domestic /
Industrial
Peripheral Water Pump
Peripheral Water Pump Description
QB series water pumps are vortex pumps with cataphoretic coating, suitable for domestic and industrial applications to convey clean
liquids and non-aggressive chemical fluids. The hydraulic
characteristic is with a higher head and bigger capacity.
Peripheral Water Pump Application
These products are mainly used in dry regions for agriculture. It
can be used for the tank, domestic water supply, water transfer,
pressure boosting, irrigation, drinking water, and living water.
Therefore, the living condition could be much improved.
Peripheral Water Pump Data ( 220V/50HZ )
| Model | Output | A | R.P.M. | Q.Max | H.Max | S.Head | Pipe Dia | LxWxH | N.W. |
| HP / KW | 1~220V | (l/min) | (m) | (M) | (mm) | (Kg) |
| QB60 | 0.5 / 0.37 | 1.6 | 2850 | 35 | 35 | 9 | 1"x1" | 280x145x180 | 5.3 |
| QB70 | 0.75 / 0.55 | 3.6 | 2850 | 45 | 50 | 9 | 1"x1" | 330x180x220 | 9.5 |
| QB80 | 1 / 0.75 | 4.8 | 2850 | 50 | 55 | 9 | 1½ "x1½" | 330x180x220 | 10 |
| QB90 | 1.5 / 1.1 | 6.2 | 2850 | 90 | 60 | 9 | 1½ "x1½" | 425x200x220 | 22 |
Other voltages and frequencies available on request
STRUCTURAL CHARACTERISTICS
| Main Specification | Standard | Optional |
| Transmission medium | Clean Water | |
| Pump body | Cast Iron | |
| Impeller | Brass | |
| Motor housing | Aluminum | |
| Stator&Rotor | 1.Cold-rolled silicon steel sheet by high-speed punching machine.
2. 100% high-quality copper wire |
| Front cover | Cast Iron | Brass plate embedded to avoid impeller jam |
| Bearing | Chinese Best Quality Bearing | NSK, SKF, or on request |
| Mechanical seal | Graphene/Ceramic | Silicon Carbon |
| Shaft | Carbon Steel | Stainless Steel |
| Insulation | Class B | Class F |
| Protection | IP44 | IP54 |
| Voltage | 220-240V Single Phase | On Request |
| Frequency | 50HZ | 60HZ |
| thermal protection | No | Yes |
| Automatic Pressure Control System | No | Yes |
| Cooling Type | External Ventilation | |
| Max. Suction lift | 9M | |
| Max. Fluid Temperature | +60℃ | |
| Max. Environment Temperature | +40℃ | |
| Installation | Horizontal | |
| Connect Type | Thread | |
| CONSTRUCTION AND SAFETY STANDARDS in compliance with IEC |
Peripheral Water Pump GUARANTEE
Guarantee for one year from shipped on board date. During the
guarantee period, our company will provide free easy-damaged spare
parts for problems caused by our quality of production or raw
material, except the damageable spare parts caused by the
customer's incorrect artificial operation. In addition, after
expiration, our company provides cost spare parts for maintenance.
OUR SERVICE
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services
from designing, printing to processing. Customers can provide the
design according to your request and sample making. Also, we can
advise how to make the products according to customers' target
prices.
FAQ
1. Q: What’s the MOQ?
A: Trial sample order is ok.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: How can I get the pump?
A: Usually, we suggest express for samples. If the volume reaches
1m³, the Seaway will be better.
5. Q: What’s the warranty period?
A: 1 year.
