Virtual Load Balancer Network TAP Security by SPAN Monitor Tools

Load Balance Network TAP for Virtual Network Security by SPAN Monitor Tools

1. Overviews

• Supported raw packet output for monitoring equipment of BigData Anlysis, Protocol Analysis, Signaling Analysis, Security Analysis, Risk Management and other required traffic.
• Supported real-time packet capture analysis, data source identification, and real-time/historical network traffic search
• The basic analysis module of traffic visualization detection function can make a summary statistical presentation of the captured target traffic data's message count, unicast/multicast/broadcast message distribution, session connection number, message protocol distribution, captured traffic size and other basic information.

2. Intelligent Traffic Processing Abilities​

Load Balance

Supported load balance Hash algorithm and session-based weight sharing algorithm according to L2-L7 layer characteristics to ensure that the port output traffic dynamic of load balancing

Mail Protocol Identify

Supported identify Email Protocol such as: SMTP, POP3, IMAP, SMTP, etc. According to user configuration, the traffic output policy can be implemented.

UDF Match

Supported the matching of any key field in the first 128 bytes of a packet. Customized the Offset Value and Key Field Length and Content, and determining the traffic output policy according to the user configuration

MAC Address Replacement

Supported the replacement of the destination MAC address in the original data packet, which can be implemented according to the user's configuration

NetTAP® Visibility Platform

Supported NetTAP® Matrix-SDN Visual Control Platform Access

1+1 Redundant Power System(RPS)

Supported 1+1 Dual Redundant Power System

NT-VPP-4860G Network TAP NPB.pdf

3. Typical Application Structures

• Network Visibility for your Traffic Data Security Application(as following)

• Data De-duplication Application(as following)

4.Specifications

5. Order Information

NT-VPP-4860G-SOFT-DIAG NetTAP^® Advanced Packet Detection/Diagnostic Software

NetTAP® (Full named Chengdu Shuwei Communication Technology Co., Ltd.)was established in 2007. Focusing on the Research and Development of Network TAPs/NPBs Communication Equipment, Data Security Analysis Equipment, which provides products and solutions in Big Data Acquisition, Data Storage, Data Monitoring, Data Processing and Data Analysis for Telecom, TV Broadcasting, Government, Education, IT, Finance, Bank, Hospital, Transportation, Energy, Power, Petroleum, Enterprise and other industries.

NetTAP® has launched various types of high-density devices such as: Fast Gigabit, 10 Gigabit Ethernet Network Traffic Replication, Aggregation, Distribution Network TAPs/NPBs (Network Packet Broker), intelligent Hybrid Traffic Network TAPs, 25G, 40G, 100G, etc. high density and Performance Network TAPs/NPBs(Network Packet Broker).

NetTAP® has a hardware production plant, all the communication products have complete Software and Hardware Independent Intellectual Property Rights, with complete Copyright Registration and Product Certification.

MATRIX NetInsight™ - A Fully Function Network Visibility Control Platform

MATRIX NetInsight™ Network System Value

1- Data Acquisition with centralized planning, eliminate monitoring blind spot

2- Free distribution of data, saving analysis of the overall investment

3- Data Security Control, Reduce the risk of disclosure

4- Overall Traffic visible, Abnormal Located more accurate, Fault analysis more useful

MATRIX NetInsight™ Function Architecture

1- User Interaction Layer

2- Big Data Analysis Layer

3- Data Storage Layer

4- Analysis Visibility Layer

5- Data Acquisition Layer

                                                                                       Zain Cloud Project of Saudi Arabia Telecom
