Non Combustiable 25oz Sliver Aluminium Foil Laminated Fiberglass
Fabric
Description:
Fiberglass fabric coated with aluminium foil has excellent
properties such as smooth surface on the aluminum foil, strong
light reflection, good stretching resistance in length and breadth,
non-breath ability, non-water permeability, good hermetic and
weather resistance.
Temperature resistant:
Fiberglass fabric: ≤550℃
Adhesive: ≤300℃
Aluminium foil: ≤300℃
Data sheet Of Basic Fabric:
Type
| C-glass/E-glass |
Item No.
| UPSE-8784 |
Thickness
| 0.8mm | 0.032inch |
Weight
| 850g/m2 | 25oz/yd2 |
Yarn weft/warp
| ECG37 1/4,ECG37 1/5 | ECG37 1/4,ECG37 1/5 |
Construction weft/warp
| 8/6 ends/cm | 8/6 ends/cm |
Temperature resistant
| ≤500℃ | ≤932℉ |
Tensile strength
| 2600/2400(N/50mm) | |
Data sheet Of UPCAL-8784:
Item
| Aluminum Foil Fiberglass Fabric |
Thickness
| 0.85mm |
Width
| 1 m, 1.2 m, 1.5 m |
Weight
| 880g/m2 |
Weave
| Satin |
Glass Yarn Type
| E-Glass/ C-Glass |
| Advantages | 95% radiant thermal reflective, Non-breath ability,Non-water permeability |
Advantage
1.Smooth surface on the aluminum foil
2.good stretching resistance in length and breadth
3.Low thermal conductivity and superior heat insulation;
4.Keeps warmth in during winter and cools in summer
5.Good fire resistance can be rated IMO part 5
6.95% heat reflection
7.Moisture barrier,water-proof, fire-retarding and anti-corrosion
8.Light weight and easy to handle
Main Application:
1.Used as the protective layer of super glass wool with excellent
functions of fire-resistance, anti-corrosion, heat isolation and
heat protection and sound absorption, sound-proof materials in
construction.
2.Heat insulation, sound absorption and noise reduction for car,
train, refrigerator car and laboratory; moisture proof cushion for
traveling
3.Packing for special products and cold storage
4.Making protective wear- gloves, covers
5.Wrapping materials of oil transportation pipelines and the steam
pipelines in the petrochemical industry, ducting with the same
effects as mentioned above
Pictures:
