Hollow Shaft Motor
Siemens Type Hollow Shaft Motor for the high-pressure pump HS100L2
Description
single-phase asynchronous motor with a hollow shaft,3HP/2.2KW 300 RPM, Single-Phase,230V 50HZ, excellent new materials,
which greatly optimizes the mechanical design, saves design space
and production cost, and is widely used in pumps, ventilation
equipment, supercharger equipment, small hydraulic power.
Generator, etc.
Model: HS100L2
Frame Size:10
Power:3HP/2.2KW
Application
H.S. series hollow shaft motor has a wide range of using, such as
with high-pressure pump for cleaners machine, washing machines, and
so on
Operating conditions:
1. Ambient temperature: -15℃≤θ≤60℃
2. Altitude: ≤1000m
3. Protection class: IP54
4. Insulation class: class F
5. Rated voltage: 220V, other voltage on request
6. Cooling type: IC 0141
7. Duty: Continuous(S1)
8. Rated frequency: 50HZ, other frequency on request
Production line
Hollow Shaft Motor
Production data
| Single-Phase 2 Poles 3000Rpm 50Hz | |
| FRAME | POWER | RPM | COSφ | EFF.% | CAPACITOR | VOLT | AMPERE |
| KW | H.P. | P.F. | | U.F. | V | A |
| 711-2 | 0.37 | 0.5 | 2790 | 0.95 | 62 | 12.5 | 230 | 2.7 |
| 712-2 | 0.55 | 0.75 | 2790 | 0.98 | 61 | 16 | 230 | 4.0 |
| 90L1-2 | 1.8 | 2.5 | 2850 | 0.95 | 65 | 50 | 230 | 12.7 |
| 90L2-2 | 2.2 | 3 | 2840 | 0.99 | 72 | 60 | 400 | 13.4 |
| 100L2 | 2.2 | 3 | 2850 | 0.96 | 74 | 85 | 400 | 15.3 |
| | | | | | | | |
| Single-Phase 4 Poles 1500Rpm 50Hz | |
| FRAME | POWER | RPM | COSφ | EFF.% | CAPACITOR | VOLT | AMPERE |
| KW | H.P. | P.F. | | U.F. | V | A |
| 711-4 | 0.25 | 0.35 | 1360 | 0.91 | 57 | 10 | 230 | 2.1 |
| 712-4 | 0.37 | 0.5 | 1380 | 0.94 | 65 | 16 | 230 | 2.6 |
| 90L1-4 | 1.5 | 2 | 1400 | 0.98 | 70 | 45 | 230 | 9.5 |
| 100L1-4 | 1.85 | 2.5 | 1390 | 0.97 | 68 | 55 | 230 | 12.2 |
| 100L2-4 | 2.2 | 3 | 1350 | 0.99 | 74 | 70 | 230 | 13.1 |
| 100L3-4 | 2.6 | 3.5 | 1350 | 0.96 | 74 | 80 | 230 | 17.5 |
| 112M1-4 | 3 | 4 | 1400 | 0.98 | 74 | 80 | 230 | 18.1 |
| 112M2-4 | 3.7 | 5 | 1410 | 0.96 | 76 | 100 | 230 | 22 |
Guarantee:
Guarantee for one year from shipped on board date. During the
guarantee period, our company will provide free easy-damaged spare
parts for problems caused by our quality of production or raw
material, except the damageable spare parts caused by the
customer's incorrect artificial operation. In addition, after
expiration, our company provides cost spare parts for maintenance.
Our service:
1. Directly factory sale
2. Quick response to 2-8hours, response rates over 92%
3. 24 hours phone call is available. Feel free to contact us.
4. All goods produced by ourselves, we provide one-stop services
from designing, printing to processing. Customers can provide the
design according to your request and sample making. Also, we can
advise how to make the products according to customers' target
prices.
FAQ:
1. Q: What's the MOQ?
A: We accept one piece.
2. Q: Are you a factory or trading company?
A: We are a manufacturer.
3. Q: Can you accept using our logo?
A: Yes, we can do OEM for you.
4. Q: What's the warranty period?
A: 1 year.
5. Q: What are the terms of payment?
A: T/T. 30% deposit and 70% against the B.L. copy or 100% L.C. at
sight.
