Poultry Aquatic Product Field Extruder Spheronizer For Making Spheroid

LTJW-5 Factory Supply High Performance Integrated Extruder Spheronizer

Function

The extruder& spheronizer mainly applied in pellets production process, using rotary screw rod to extruding the wet material out of spheral screen, the extruded strips drop into the spheronizer disk plate, then strips divide and roll on the rotary disk plate by centrifugal force of the high speed rotary disk plate, and finally it become round and solid pellets.

compared other ways of making pellets, extruding and spheronizing technique has following features:

- the whole process executed in a wet status without dust rise.

- product yield beyond 99%, with small particle size distribution, qualified product above 90%.

- finished pellets have good roundness and strength, the density can reach more than 0.8g/cm3. Especially good for coating on the pellets to make controlled-release drugs.

- the pellets have good drug loading capacity, it have wide drug loading range

- it is easily to mix the incompatible active contents.

- the loss of zymin can be reduced less than 10% during enzymic preparation

- high efficiency, low cost and low labor intensity

- good process reproducibility, parameterization process procedure, easy to control and manage.

Technical Data

Complete Set

Characteristics

1) Finish pelletizing process in on step.

2) Adopting DC brushless motor and planetary gear reducer transmission system, have compact structure, it is convenient to maintain without adding lubricant.

3) Adopting 5-axies drilling techniques for the extruding spheral screen machining, which makes extruding evenly and high efficient.

4) In-built with cooling channel, the user can choose air-cooling or water-cooling.

5) There are current monitor and overload protection designed for the equipment safety.
