    Cement Clinker Handling Belt Conveyor High Temperature Resistance

    Ask Lasest Price
    Brand Name : PK
    Model Number : DTIIA
    Certification : CE Certificate,ISO14001:2015, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 600SETS/YEAR
    Delivery Time : ABOUT 35 DAYS
    • Product Details
    • Company Profile

    Cement Clinker Handling Belt Conveyor High Temperature Resistance

    Cement Clinker Handling Belt Conveyor High Temperature Resistance


    Introduction

    Belt Conveyor is the essential and economical transferring set in the uninterrupted production line.it consists of standard parts ,and easy maintenance so widely used in mining ,metallurgy and chemical industry to transfer stone materials or packaged materials, compared with other transportation equipment (such as locomotive), it has the advantages of long conveying distance, large capacity, continuous transportation and reliable operation, easy to achieve automation and centralized control, Belt Conveyor has become the key equipment in mining process.


    Advantages and Features

    1. Can adopt combined conveying mode of convex curved segment,concave curved segment or straightline segment.
    2. According to different transportation request, it can be single used or multiple combined using, also can be used together with other equipments to organize a horizontal or declining conveying system.
    3. Conveyor length can be customized according to your need.
    4. Belt conveyor cleaner can be installed to clean the conveyor belt.
    5. Conveyor rollers are manufactured by our roller production line to ensure smooth conveyor system.



    Technical datas:

    Roller formRunning speed(m/s)Belt width (mm)
    500650800100012001400
    capacity(m3/h)
    Trough roller0.878130--------
    1.097164278435655891
    1.251222063485448211115
    1.615626444569610481427
    2.019132354685312841748
    2.5232391664103315562118
    3.15----824123318582528
    4.0--------22022996
    Falt roller0.84167118------
    1.05288147230345469
    1.2566110184288432588
    1.684142236368558753
    2.0103174289451677922
    2.51252113505468211117


    Selection Conditions


    ♦ Material to be processed:


    ♦ Installation angle:

    ___°(if the installation is inclined)

    ♦ Bulk density:

    t/m3

    ♦ Lifting height:

    ___m (if there is slope angle)

    ♦ Water content:

    %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature:

    °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material:

    mm

    ♦ Working environment:

    (indoor or outdoor)

    ♦ Max. Granule size:

    mm

    ♦ Working environment temperature:

    °C

    ♦ Handling capacity:

    t/h

    ♦ Working power supply:

    3 Phase V Hz

    ♦ Conveying length:

    m

    ♦ Quantity:

    sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
