    Incline Loading Fertilizer Roller Belt Conveyor With Rain Covers​

    Ask Lasest Price
    Brand Name : PK
    Model Number : DTIIA
    Certification : CE Certificate,ISO14001:2015, BV, SGS,Business-license,Certificate of environment management system certification
    Price : Negotiable
    Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram
    Supply Ability : 600SETS/YEAR
    Delivery Time : ABOUT 35 DAYS
    • Product Details
    • Company Profile

    Incline Loading Fertilizer Roller Belt Conveyor With Rain Covers​

    Incline Loading Fertilizer Roller Belt Conveyor With Rain Covers​


    Introduction

    This product is the new improved product of DT II Series. It can be used in industries such as coal mine, port, power station, building material, metallurgy and so on.

    Transporting various kinds of granular materials or goods whose bulk density is from 0.5t/m to 2.5t/m. Its operating temperature is defined from -25ºC to 40ºC.

    This capable of horizontal machine is transporting and slanting transportation,combining curved segment transporting and concave-convex straight-line segment transporting.


    Advantages and Features

    1. Outstanding performance: Remarkable transporting ability, small transportation resistance,low power consumption,widely used in different Industry fields.

    2. Different belt width can meet your requirement, conveyor belt width ranges from 500~2400mm.

    3. Adapt to the hot/cold-resistant sticky tape conveyor of the open-air homework of hot and cold area.

    4. We are professional conveyor system supplier, we can manufacture the conveyor system according to customers' demands.

    5. Easy maintenance, large conveying capacity, energy-saving and low cost.

    6. Widely application area: Can widely applied to grain, salt, ore, sand, coal, mineral, chemical, power plant, metallurgy, etc.



    Technical datas:

    Roller formRunning speed(m/s)Belt width (mm)
    500650800100012001400
    capacity(m3/h)
    Trough roller0.878130--------
    1.097164278435655891
    1.251222063485448211115
    1.615626444569610481427
    2.019132354685312841748
    2.5232391664103315562118
    3.15----824123318582528
    4.0--------22022996
    Falt roller0.84167118------
    1.05288147230345469
    1.2566110184288432588
    1.684142236368558753
    2.0103174289451677922
    2.51252113505468211117


    Selection Conditions


    ♦ Material to be processed:


    ♦ Installation angle:

    ___°(if the installation is inclined)

    ♦ Bulk density:

    t/m3

    ♦ Lifting height:

    ___m (if there is slope angle)

    ♦ Water content:

    %

    ♦ Upstream equipment (what kind of equipment is used to feed the material):

    ♦ Material temperature:

    °C

    ♦ Downstream equipment (what kind of equipment is used to discharge the material):

    ♦ Material is corrosive or not:

    (Yes or No)

    ♦ Motor and gearbox: (Domestic or International brand or designated brand?)

    ♦ Material is sticky or not:

    (Yes or No)

    ♦ Construction material: (Carbon steel, SS304, SS316L or any special requirements)

    ♦ Granule size of material:

    mm

    ♦ Working environment:

    (indoor or outdoor)

    ♦ Max. Granule size:

    mm

    ♦ Working environment temperature:

    °C

    ♦ Handling capacity:

    t/h

    ♦ Working power supply:

    3 Phase V Hz

    ♦ Conveying length:

    m

    ♦ Quantity:

    sets

    ♦ Installation of the conveyor is inclined or not: ___ (Yes or No)
