in China, our FO calbes are equipped with advanced technology and
many highly qualified staff.
Please be free to wholesale the customized products with us.
Single mode or multimode fibres are position in a loose tube made
of a high modulus plastic.
The tube are filled with a water resistant filling compound.
A steel wire,sometimes sheathed with ployethylene(PE) for cable
with high fiber count,
locates in the center of core as a metallic strength member.
Tubes (and fillers) are stranded around the strength member into a
compact and circular cable core.
The cable core is filled with filling compound to protect it from
water ingress,
over which a thin PE inner sheath is applied.After the PSP is
longitudinally applied overthe inner sheath,
the cable is completed with a PE sheath.
Description
FTTH outdoor cable, the optical fiber unit is positioned in the
center.
Two parallel Fiber Reinforced steel wires(or FRP) are placed at the
two sides.
Then the cable is completed with a black or color LSZH sheath.
Advantages
Special low-bend-sensitivity fiber provides high bandwidth and
excellent communication transmission property;
Two parallel steel wire/FRP strength members ensure good
performance of crush resistance toprotect the fiber.
Simple structure, light weight and high practicability;
Novel flute design, easily strip and splice, simplify the
installation and maintenance;
Low smoke, zero halogen and flame retardant sheath.
Product perameter
| Model Number | GJXH,GJXFH |
| Type | Coaxial |
| Number of Conductors | 1--12 |
| Certification | UL ROHS ISO |
| OEM | Welcome to OEM for FTTH outdoor Cable |
| Item | FTTH outdoor Cable |
| Jacket Material | LSZH |
| Laying method | FTTH/FTTX/FTTA |
| Standards | YD/T 1258.2-2003,ICEA-596,GR-409,IEC794,OFNR & OFNP |
| Application | Outdoor wiring, building introduction |
| Operating Temperature | -40 to 70 degree |
Technical Parameters
| Fiber count | | Cable | Tensile Strength | Crush Resistance | Bending Radius |
| Cable Diameter | weight | Long/short term | Long/short term | Static/Dynamic |
| mm | kg/km | N | N/100mm | mm |
| 1 | (2.0±0.2)*(3.0±0.2) | 8 | 30/60 | 300/1000 | 15/30 |
| 2 | (2.0±0.2)*(3.4±0.2) | 8.5 | 30/60 | 300/1000 | 15/30 |
| 1 | (2.0±0.2)*(3.8±0.2) | 9 | 30/60 | 300/1000 | 15/30 |
| 4 | (2.0±0.2)*(4.0±0.2) | 10 | 30/60 | 300/1000 | 15/30 |
