    Electrical Hot Melt Butyl Extruder / Adjustable Extrusion Coating Machine

    Ask Lasest Price
    Brand Name : LIJIANG
    Model Number : LJTB01
    Certification : CE
    Price : negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 500 sets per month
    Delivery Time : 30
    • Product Details
    • Company Profile

    Electrical Hot Melt Butyl Extruder / Adjustable Extrusion Coating Machine

    Electrical Hot Melt Butyl Extruder / Adjustable Extrusion Coating Machine


    Hot Melt Butyl Extruder Application


    The type of LJTB01 Hot Melt Butyl Extruder is used for spreading aluminum spacer frames evenly with hot melt butyl. This equipment use large electrical control panel which makes the operation more easier. The conveyor of aluminum is controlled by frequency converter, and the speed can be adjusted from 0m/min to 47m/min, which has the fastest speed in China. It is very popular with energy-saving. Its squeezing system adopts pneumatic and hydraulic supercharging system, which makes the squeezing pressure more stable. The dispensing cylinder uses vertical rotary support system and it makes the refill of butyl easier. It can prolong the life of squeezing system and set the heating time in 24 hours with electricity and air pressure. The distance of squeezing head can be adjusted automatically according to different aluminum spacer. The machine has reached the worldwide technology with the characteristic of complete function and stable working mode.

    on. Successfully displaying IG units products to customers all over the world.


    Hot Melt Butyl Extruder features


    1. Filter out debris automatically through auto exhaust, keep spreading quickly and evenly.

    2. Quickly speed of warming, improve work effect.

    3. Adjustable coating speed, can up to 0-47m/min.

    4. Can save about 40% materials, only 5g/m.

    5. Extruder head height adjustment structure.

    6. Automatic centering and clamping structure.

    7. Stable temperature and it is convenient to adjust the sealing material automatically.


    Hot Melt Butyl Extruder Technical Data


    Squeeze pressure10-18MPa
    Temperature110~140℃
    Aluminum spacer width4-30mm
    Speed0-47m/min
    Diameter of butyl cylinder200mm
    Air supply0.4m³/min
    Air pressure≥0.6MPa
    Total power380V, 5KW, 50HZ
    Dimension2600×680×1100mm(L×W×H)
    Weight650kg

    Hot Melt Butyl Extruder Main components


    NameBrandOriginal
    PLCKINCOChina
    ValveHAWEGerman
    Low voltage electrical apparatusSIEMENSGerman
    Hydraulic and pneumatic supercharging systemMAXIMATORGerman
    Frequency converterKINCOChina
    Pneumatic components(cylinder/valve)ARTACTaiwan
    Quick exhaust valve/Vacuum generatorSMCJapan SMC
    Travel lightOMRONJapan
    Optical fiberOMRONJapan

    Hot Melt Butyl Extruder Details



    Our Service

    After-sales service

    *Training how to instal the machine, training how to use the machine.

    * Engineers available to service machinery overseas.
    * We are always online service you when your machine meets some problems.
