    Direct Buried Electrical Post Transmission Electrical Power Pole ISO Passed

    Ask Lasest Price
    Brand Name : JSHG
    Model Number : HG-SP
    Certification : ISO/CNAS/IAF/CA
    Price : negotiation
    Payment Terms : L/C, T/T or Western Union
    Supply Ability : 3,000 Metric Tons per Month
    Delivery Time : 1 week
    • Product Details
    • Company Profile

    Direct Buried Electrical Post Transmission Electrical Power Pole ISO Passed

    Direct Buried Electrical Post Transmission Electrical Power Pole Steel Tubular Pole

    Product Description:

    1) Steel materials conform to ASTM A36 with Q235(S235,SS400),Q345(S355JR), Q460,etc

    2) Welding: Welding complies with CSA and AWS, AWS D1.1 standard.

    3) Finish: Hot-dip galvanized in accordance with ASTM A123. Min Zinc Coating 86 microns.

    4) Pole Height: Transmission pole ≥ 15M

    5) Pole shape: Conical, Round, Polygonal---Octagonal, Dodecagonal, Hexadecagonal, etc

    6) Type: Straight Pole ,Tensile Pole ,Turn Pole (Double-loop corner pole, Single or double loops/circuit pole, single or double tensile/terminal/straight pole, etc)

    Product Specification:

    Products
    • Direct Buried Electrical Post Transmission Electrical Power Pole Steel Tubular Pole
    Application
    • Power transmission and distribution Line
    Voltage Grade
    • 10~500KV
    Once Forming
    • 16m Once forming without joint
    Shape
    • Round / polygonal / Conical / Tubular
    Welding
    • According to AWS D 1.1, CO2 welding or submerged arc auto methods
    Joint
    • Joint with insert mode, flange mode.

    Painting

    • According to clients' request

    Galvanization

    • 15m steel pole is hot dip galvanized in accordance with Chinese standard GB/T 13912-2002 and American standard ASTM A123.

    Product Advantages:

    1.Short Construction Cycle
    2.Low Overall Cost
    3.Easy Installation and Maintenance
    4.Weather Resistance
    5.Anti-corrosion
    6.More than 15 Years Design & Manufacture Experience
    7.Capable to Handle Volume Orders
    8.Provide Professional Design by Our Experienced R&D Engineers
    9.Rich Exporting Experience
    10.ODM, OEM Acceptable
    11.Technical Support by E-mail


    Application Scope:

    Steel tube tower mainly use between high voltage transmission lines, with lightning rod hanging place on top, bolt connecting tower body with cross arm which has wires hanging place. The intersecting surface of tower is oblong, and the intersection surface macroaxis of tower and cross arm is 0 to 90 degree angle. In practical application, raw material can be saved of shorten the circumference of intersection surface by bearing the max bending moment of oblong intersection surface macroaxis.

    Packaging&Shipping:

    * Covered by Plastic Wrap or Mat or according to client's requests.
    * The Loading Pcs of Each Container could be calculated according to client's specification and data.

    Manufacturing:

    Raw material: Q235 or Q345 in China. We get the raw material checked in our lab test room. Silicon less than2%. We have carbon and sulfur analyzer to check the elements of the steel sheet. We'll return the steel if they are unqualified. So in this way, we can control the quality of the steel poles from the first beginning.

    Our factory owns advanced production lines and machines including bending calibration machine, hydraulic plate shears machine, shears machine, slitting machine, 208T hydraulic straightener, etc. All insure us to produce steel poles with the best quality.

    After the fabrication process as cutting plate, bending, forming, automatic welding, drilling holes, we get poles checked before galvanized, hot dip galvanized and powder coating and finally we get poles checked according to client's requirements.

    Contact Us:

    Jiangsu Hongguang Steel Pole Co., Ltd.
    Address: Wanshi Industrial Zone, Yixing City, Jiangsu Pro., P.R.China, 214212
    Telphone: +86 510 878 441 56
    Fax: +86 510 878 435 28
    Trade manager ID: cnhgsteelpole
    Skype: tangjia870124

    Please feel free to contact us!
