6000L Centralized Flat Plate Solar Water Heater Solar Thermal Flat
Plate Solar Collector
Product Details
Flat plate solar water heater
1. Reliable solution
2. Easy plug-in installation
3. Water in tank can be used as potable water
4. Perform better in warmer areas with lots of direct sunlight
5. Works under high pressure
6. Stable solar conversion during the day
7. Back up electric heater can be used with 1500/2000/3000W
8. Instant heat exchange, hot water can be used directly or can be
used as a pre-heater
9. Stable water output
Absorber
1. Selective black chrome.
2. Selective blue sputtering.
3. Selective anode oxidation coating.
4. Selective black painting.
Features
1. full-copper TP2 or aluminum-copper complex absorber.
2. Ultrasonic welding technology,100% fusion between riser tube and
fin.
3. High-efficiency selective absorber coating,high absorption and
low thermal emission.
4. Corrosion and pressure proof.
Frame casing
1. durable corrosion-resistant and elegant-design aluminum alloy
frame.
with anodized anti corroded surface.
2. Multicolor surface of the frame casing.
3. Typhoon-proof and sea-water resistant design.
Glass cover
1. 4mm tempered patterned glass,transitivity87%
2. 3.2mm/4.0mm tempered,low-iron patterned solar glass,transitivity
up to 92%
Insulation
40mm high quality soft fiberglass layer +25mm high-density
fiberglass plate,minimum the heat loss.
Flat Plate Solar Collector Technical Data :
| Model | PT-F-BT |
| Data |
| Dimension LxWxH (mm) | 2000*1000*80 | 2000*1250*80 | 2000*1500*80 |
| Gross Area (m2 ) | 2.00 | 2.50 | 3.00 |
| Absorber Area (m2 ) | 1.9 | 2.38 | 2.85 |
| Number of covers | 1 |
| Cover Material | Low iron tempered textured glass |
| Cover Thickness(mm) | 3.2 |
| Cover Transmission | >91.7% |
| Absorber |
| Absorber material | Aluminium Plate |
| Absorber coating | Blue Titanium |
| Welding | Ultrasonic welding |
| Construction Type | Grid type |
| Header Material | Copper TP2 |
| Header pipe | Red copper/ Φ22*0.6*2 PCS |
| Riser Material | Copper TP2/CA1220 |
| Riser pipe | Red copper Φ8/10*0.5*7 PCS | Red copper Φ8/Φ10*0.5*9 PCS | Red copper Φ8/Φ10*0.5*11 PCS |
| Work Pressure | 0.6Mpa |
| Test pressure | 1.2Mpa |
| Thermal Insulation |
| Insulation Material | Fiberglass |
| Insulation Thickness | 40mm |
| Casing |
| Frame | Aluminium alloy |
| Frame Colour | Silver/Black |
| Back Plate | Galvanized steel |
| Sealing Gasket | EPDM |
| Loading Quantity |
| Quantity (20FT container) | 150PCS | 120PCS | 95PCS |
Packaging & Shipping
Packaging Details: Export strong corrugated carton.
Delivery Detail: Within 7 - 10 days for container order quantity
upon confirmed invoice or sales contract.
FAQ
1. Technical support: We offer design and installation instruction
with 10 years installation experience.
2. OEM: Your LOGO information can be made on our Flat Plate Panel
Solar Collector and carton boxes.
Catalogue of Flat Plate Solar Collector.
PT-F Flat Panel Solar Collector.pdf
