    34 Heads Design LED Mounting Machine Windows 7 System high speed smt placement machine

    Ask Lasest Price
    Brand Name : ETON
    Model Number : HT-XF
    Price : EXW USD 45000/sets
    Payment Terms : L/C, T/T
    Supply Ability : 50 sets per mouth
    Delivery Time : 30 days after deposit
    Certification : ccc,ce,rise
    • Product Details
    • Company Profile

    34 Heads Design LED Mounting Machine Windows 7 System high speed smt placement machine

    Dual purpose professional high speed mounter ,the capacity reach 170000CPH


    Special LED mounter


    apply to the 0.6m,0.9m.102mLED rigid PCB and0.5m,1m flexible strip.


    Visual system


    5 sets of imported camera;Vision alignment ,mark correction


    The imported camera can accurately identify the exact position of PCB board and the position of components and board. The overlooking camera searches for the target on the circuit board (as a benchmark) in order to place the circuit board in the correct position before assembly, and the overlooking camera is used to detect elements in the fixed position.


    Maximize Time Saving and Improve Production Efficiency


    The products to be mounted can cover the whole platform and realize the cycle production.


    The camera is installed between the pickup position and the installation position. The acquisition and processing of the video can be carried out simultaneously during the movement of the installation head to shorten the installation time.


    High Speed and High Precision


    This special Mounter has a speed of 150000~170000 CPH.Can save space, labor costs, management costs


    No. Of feeder station:34PCS nozzles:34PCS


    It has a set of vision recognition system, which can process the absorbed components into the required mounting angle through image recognition, and realize high precision mounting, with an accuracy of 0.02mm.


    Good durability


    Using High Stability Electronic Dual Motor


    The wear resistance of screw rod is not easy to deviate and has high accuracy.


    The guide rail has strong bearing capacity and high stability.


    High-quality hardware configuration for 24-hour machine operation.






    HT-XF
    PCBPCB length widthMax:330*1200mm min:90*330mm
    PCB thickness0.5~5mm
    PCB clampingAdjustable pressure pneumatic
    Mounting modeGroup to take and group to mount
    O.S.systemWindows 7
    softwareR&D independently
    displayLED monitor
    Input deviceKeyboard , mouse

    Vision

    system

    No.of camera

    5 sets of imported camera

    Vision alignment,mark correction

    Mounting precision0.02mm(repeat precision)
    Mounting height<15mm
    Mounting speed150000~170000CPH
    ComponentsLED 3014/3020/3528/5050 and resistors,capacitors ,bridge rectifiers.
    Components space0.2mm
    No.of feeders station34PCS
    No.of nozzles34PCS
    Power220AC 50HZ
    Power consumption5KW
    Conveyor transmissionMax length:1200mm
    Transmission speed>500mm/sec
    Transmission directionSingle (left to right or right or left)
    Transmission modeAuto online drive
    Position modeOptical
    Air pressure>5.0kg /cm²
    Electrical controlIndependent research and development by ETON
    Motion control card module 1setIndependent research and development by ETON
    X,Y,X axis drive wayServo motor control for X,Y,Z axis
    Feeding wayElectric feeder with double motor
    Company Information


    Honour show


    ETON advanced technology and innovation drives the revolution of market rapidly ,and obtains a number of intellectual property technologies.

    Including 9 invention patents,112practical patents,12 software copyrights.



    Our Cooperators


    We have many excellent overseas customers and maintain long-term cooperative relationship. Customers are very satisfied with our products.



    After-sale Service


    we will send our engineer to your factory to install machine and training freely.

    We have service office in india,and have indian engineer in delhi and mumbai.Can support quickly.

    Standard warranty is one year,during warranty,any parts need to be repaired and replaced will be free.


    FAQ

    1.What’s the terms of payment? What about the trade term?

    T/T is OK. You can choose FOB Shenzhen.


    2.What is the delivery date?

    We will deliver the goods after 30 days' deposit.


    3.What mode of transport does the goods adopt?

    Our mode of transportation is very flexible.Our mode of transportation including water, land and air transportation.You can choose the most suitable way according to your requirements.
